Procedure 9-1 (continued)
Platform upgrade from a NAC 1 system to a NAC 2 system
Step Installer's action and system's response
One Network Link must be assigned for each Meridian MAX node in the network. At
least one Network Link must be assigned at all times. There are two ways to access
a Meridian MAX node as a remote supervisor. A direct connection Remote Login link
can be assigned on the NAC for each Meridian MAX node. Alternatively, one or more
modem connection Remote Supervisor Login links can be assigned on the NAC to
access any of a group of Meridian MAX nodes. A combination of the two methods
can be used.
Printers and Displays
You must assign at least one Printer and one Supervisor Display.
Each time a printer is selected, a message appears at the bottom of the screen
asking the installer to enter a printer name for the assigned port in the
Name/Comment field.
Enter a unique name in the Name/Comment field that identifies the printer. For
example, if a tabular printer is assigned, the name TabPrint could be used.
Note: The default printer must have a name defined in the Name/Comment field
before you are allowed to exit this screen.
Printer models are listed when you press {PF2} while in the Device field. Select the
model appropriate to the printer connected to the assigned port.
When all of the peripherals are assigned to ports, press {F6} to view or change the
default printers. The system displays the Customer Default Printer Information
pop-up menu which contains the Customer Default Tabular Printer name and the
Customer Default Graphic Printer name.
To modify the Customer Default Tabular Printer field, press {PF2} and select the
name of the printer you want to use as the default tabular printer. This printer is now
the destination for all tabular reports whenever the default output device is selected.
To modify the Customer Default Graphic Printer field, press {PF2} and select the
name of the printer you want to use as the default graphic printer. This printer is now
the destination for all graphic reports whenever the default output device is selected.
Network Administration Center (NAC) Installation Guide Product release 2
—continued—
Platform upgrades 9-27
