Procedure 4-14 (continued)
Configuring the Ven-Tel 2400 Plus II modem for network link
Step Action
8 Make sure the modem at the Meridian
MAX site is properly connected and
powered up. The NAC initiates the
signal that connects the modems.
9 Connect the modem directly to the NAC
using an NT7D99AA (AM) modem
cable. Make sure the modem is
connected to the telephone system with
an RJ-11 cable/connector.
10 Power up the modem.
Network Administration Center (NAC) Installation Guide Product release 2
Response
The NAC modem will dial the Meridian
MAX telephone number as recorded
during Step 5.
The connection between the NAC site
and the Meridian MAX site is confirmed
when the Carrier Detect (CD) LED
remains constantly on.
If your NAC system is powered up and
fully functional, you should see the LED
labelled "TR" light up on the front panel
of the modem. If the "TR" LED does not
light up, retry this procedure. If the light
still does not appear, contact your
Northern Telecom representative.
—end—
Peripheral devices 4-89
