4-50 Peripheral devices
Procedure 4-5
Configuring the UDS 2440 modem via the front panel for remote diagnostics
Step Configuration action and system response
1 Connect the modem to a power source next to the NAC system. Ensure that the
modem is not connected to the NAC system at this point.
2 Position the power switch on the rear panel of the modem to ON.
Press either the {YES} or {NO} buttons on the front of the modem panel for each
response appearing in the LCD window.
If the wrong button is pressed, press the {TALK/DATA} button followed by the
{NO} button. This action returns you to Step 2.
The LCD on the front panel displays the following:
####–## (e.g. 3050–5C, appears for two seconds)
OFFLINE
3 Press {NO}.
DIAL?
4 Press {NO}.
TEST?
5 Press {NO}.
AUTO ANS?
6 Press {NO}.
DATA OPTS?
7 Press {NO}.
OPTIONS?
553-4011-110 Standard 1.0 November 1994
—continued—
