Procedure 6-1
New installation of the NAC 2 system: customer-installed software
Step Installer's action and system's response
1 Before beginning the software installation, ensure that the MVME167-34 card has
been configured correctly. Refer to the "Hardware installation" chapter.
2 Make sure the power is turned off.
3 Insert the NAC 2 operating system tape.
4 Power up the module. The power switch is located on the left-hand side of the AEM
module. The upper switch controls the power for the module in the left side of the
Meridian 1, while the lower switch controls the power for the module in the right side.
The system displays the copyright and hardware configuration information. The mes-
sages below may differ from your system messages.
Copyright Motorola Inc. 1988 – 1993, All Rights Reserved.
MVME167 Debugger/Diagnostics Release Version 1.5 – 02/14/93
COLD Start
Local Memory Found =02000000 (&33554432)
MPU Clock Speed =33Mhz
Autoboot in progress... To abort hit <BREAK>
5 Press {BREAK} to stop the hard disk load and begin the tape load.
Note: {F5} on the VT420 is the {BREAK} key.
––Break Detected––
167–Bug>
Network Administration Center (NAC) Installation Guide Product release 2
—continued—
New software installations 6-3
