9-34 Platform upgrades
Procedure 9-1 (continued)
Platform upgrade from a NAC 1 system to a NAC 2 system
Step Installer's action and system's response
NAC to Node Login Password
The NAC to Node Login Password field defines the password used by the system to
bring up the Network Link between the NAC and its Meridian MAX nodes. If this
field is changed then the Network Administrator Password field at each Meridian
MAX node (not to be confused with the Network Administration Password in this
feature) must be changed to match it. To enter the NAC to Node Login Password,
press {PF3}, type the NAC to Node Login Password and press {PF3} again or type
the NAC to Node Login Password and press {RETURN}.
Statistics Transmission Rate
The Statistics Transmission Rate field determines how often information from the
nodes will be received. This information appears on the NAC displays. The number
you enter represents the number of seconds between each node's update. You may
select 10, 20, or 30 seconds from the menu. This field should not be confused with
each network supervisor's Stats Update Rate field (found in the Supervisor
Definition feature). The Statistics Transmission Rate determines how often a node's
information is collected. The Stats Update Rate field determines how often the
information displays are updated for the network supervisor. To select the Statistics
Transmission Rate, press {PF2}. Move the cursor to the selection and press
{RETURN} or enter the selection number and press {RETURN}.
After you have entered your information, press {PF1} and select the Save changes
and exit command.
56 After you have entered the information, press {PF1} and select the 'Save changes
and exit' command. The system saves your entries.
57 The Configure NAC System screen is returned. Enter 4, followed by {RETURN} to
exit.
58 When you have completed the system configuration screens, the system continues
with the installation.
If you switched the platform upgrade to a new installation, go to Step 60.
59 Remove the tape from the tape drive.
<<<< Finished Phase II of Database Conversion
60 The system continues with the installation.
553-4011-110 Standard 1.0 November 1994
—continued—
