4-58 Peripheral devices
Procedure 4-6 (continued)
Alternative procedure for configuring the UDS 2440 modem via workstation for re-
mote diagnostics
Step Action
4 Set the workstation baud rate to 2400.
Refer to the "Workstation" section,
"Video display terminal (VDT)
workstation" subsection for more
information.
5 Enter the following commands on the
workstation keyboard, pressing
{ENTER} after each command.
atz
at&f
ats0=1
at&d3
at&s1
at&c1
at&w
6 Power down the workstation and the
modem.
7 Disconnect the workstation from the
modem.
8 Connect the modem directly to the NAC
I/O panel using an NT7D61Ax modem
cable. Make sure the modem is
connected to the telephone system with
an RJ-11 cable/connector.
553-4011-110 Standard 1.0 November 1994
Response
OK
OK
OK
OK
OK
OK
OK
—continued—
