Procedure 4-15 (continued)
Configuring the Ven-Tel 9600 Plus modem for network link
Step Action
at\q3
ats64=1
ats0=1
at&z1=t#######
####### must be replaced with the
correct telephone number for the
Meridian MAX node.
atq1
ate0
The following command does not
appear on the screen when you enter it.
at&w1&y1
6 Power down the workstation and the
modem.
7 Disconnect the workstation from the
modem.
8 Make sure the modem at the Meridian
MAX site is properly connected and
powered up. The NAC initiates the
signal that connects the modems.
9 Connect the modem directly to the NAC
using an NT7D99AA modem cable.
Make sure the modem is connected to
the telephone system with an RJ-11
cable/connector.
Network Administration Center (NAC) Installation Guide Product release 2
Response
OK
OK
OK
OK
NONE
NONE
NONE
The NAC modem will dial the Meridian
MAX telephone number as recorded
during Step 5.
The connection between the NAC site
and the Meridian MAX site is confirmed
when the Carrier Detect (CD) LED
remains constantly on.
—continued—
