4-64 Peripheral devices
Procedure 4-8
Configuring the Racal VI2422PA dial-up supervisor modem—remote end
Step Action
1 Connect a workstation with data format
8N1 and 2400 baud to the modem with
a straight-through NT1R03Dx or
NT1R03Ex cable.
2 Connect the workstation and the
modem to their power sources. Make
sure the modem is connected to the
telephone system with an RJ-11
cable/connector.
3 Power up the workstation and the
modem.
4 Enter the following commands,
pressing {ENTER} after each
command.
at&f
at*f0
ats0=1
atq1
ate0
The following command will not appear
on the screen when you enter it.
at&w
5 Through the use of the Racal modem's
front panel, choose option 1 and set the
value to 1. Choose option 13 and set
the value to 2.
6 Use the Hayes AT command "atdt####"
for touch-tone dialing and "atdp####"
for pulse dialing to dial the required
number.
(where #### is the telephone number of
the NAC modem)
553-4011-110 Standard 1.0 November 1994
Response
OK
OK
OK
OK
OK
OK
