4-94 Peripheral devices
Procedure 4-16 (continued)
Configuring the Racal VI2422PA modem for network link
Step Action
atq1
ate0
The following command will not appear
on the screen when you enter it.
at&w
5 Power down the workstation and the
modem.
6 Disconnect the workstation from the
modem.
7 Connect the modem directly to the NAC
using an NT7D99AA modem cable.
Make sure the modem is connected to
the telephone system with an RJ-11
cable/connector.
8 Power up the modem.
9 Through the use of the Racal modem's
front panel, choose option 1 and set the
value to 1. Choose option 13 and set
the value to 2.
10 Make sure the modem at the Meridian
MAX site is properly connected and
powered up. The NAC initiates the
signal that connects the modems.
553-4011-110 Standard 1.0 November 1994
Response
NONE
NONE
NONE
The NAC modem dials the Meridian
MAX telephone number as recorded
during Step 4.
The connection between the NAC site
and the Meridian MAX site is confirmed
when the carrier detect (CD) LED
remains constantly on.
—end—
