Procedure 6-1 (continued)
New installation of the NAC 2 system: customer-installed software
Step Installer's action and system's response
31
Fields
The NAC Communication Port Assignment screen has seven fields: Assigned
Displays: #; Printers : #, Available Ports: #, Port, Device , Connect , Baud , and
Name/Comment .
Assigned Displays: #; Printers: #
The Assigned Displays: #; Printers : # field indicates the number of printers and
displays that have been assigned to available ports. This number is represented by
the number sign ( # ) in the screen examples.
Available Ports: #
The Available Ports field lists the number of ports that have yet to be assigned to
displays, printers, network links or remote logins. This number is represented by the
number sign ( # ) in the screen examples.
Port
The Port field lists the ports.
The ports are listed according to their card number, and connection number and
letter. The card number refers to the card slot number in which the card is located.
The card number begins at Card 2, Connection 1A because the CPU resides in the
first card slot. The connection number refers to the port connection on the generic
Input/Output panel. The connection letter refers to the specific port to which the
devices are attached. A NAC 2 system can have 8, 16, 24, 32 or 40 ports. If your
system has more than 16 ports, all of the ports cannot be viewed on a single screen.
Use the up and down arrow keys to scroll the screen to view the rest of the ports.
Not every port has to be assigned but you must assign at least one network link, one
printer and one supervisor workstation.
Device
To assign a device, move the cursor to an empty Device field and press {PF2} to
view a pop-up menu of the devices available for your system.
