8-28 Software reinstallations and upgrades
Procedure 8-1 (continued)
Software reinstallation or upgrade to a NAC 2 system
Step Installer's action and system's response
44 To define your Network Definition, enter 2, followed by {RETURN}.
The NAC Network Definition/Installation screen contains all of the information the
system needs to communicate with its Meridian MAX nodes. It is essential that the
information entered here match the already set up hardware connections. For
example, if the Network Link between the Toronto node and the NAC uses dial-up
modems running at 9600 baud, then 9600 should be selected for the baud field for
that specific link.
The system displays the NAC Network Definition/Installation screen:
NAC Network Definition / Installation
Node
Addr Node Name
338 TORONTO
366 OTTAWA
446 RICHARDSON
646 MOUNTAINVIEW MTV –3.0 9600 C3–2C
655 SANTA CLARA SCL –3.0 9600 C4–1B
761 EDMONTON
862 MONTREAL
F1=Commands F2=Options DELETE=Delete record
Note:
You cannot have both a remote login port and a remote login directory
number for the same MAX node.
553-4011-110 Standard 1.0 November 1994
Short Time Connection ––––––Remote Login–––––– Ntwk
Name Zone Baud Port Port Directory Number Link
TOR 0.0 9600 C3–2A
OTT 0.0 9600 C4–1A C4–3A
RCH –2.0 9600 C2–1A
EDM –2.0 9600 C4–1C
MTL 0.0 9600 C4–2A
Dsbl
Enbl
Dsbl
6,338,5980196 Enbl
6,646,3958465 Enbl
Dsbl
9,1,613,9660010 Enbl
—continued—
