Required equipment and materials

Table 3-1
NAC installation equipment and material list
Equipment
NAC with console
Cables
Network Administration Center (NAC) Installation Guide Product release 2
Table 3-1 lists the equipment and materials required for a NAC installation.
Contents
Motorola MVME712M transition card
Motorola NT6D51AA transition card (maximum of 5)
Motorola P2 adapter board
1.2 Gbyte Seagate ST11200N hard disk drive
600 Mbyte Teac MT-2ST/F5OB-413 cassette drive
Motorola MVME167-34 single board
computer with:
33 MHz M68040 CPU
32 Mbyte DRAM
M68882 math coprocessor
4 RS-232C communication ports
SCSI bus interface with DMA
Motorola MVME332XT eight-channel asynchronous I/O board
(maximum of 5)
Mass storage unit (MSU) containing disk and tape drives
AC or DC power supply
3 Multiport assemblies (NT8D96AE) for each MVME332XT
Asynchronous Communication controller
External input/output cables (refer to the "Cables" section for
more details)
—continued—
