Procedure 4-5 (continued)
Configuring the UDS 2440 modem via the front panel for remote diagnostics
Step Configuration action and system response
67 Connect the modem directly to the NAC generic I/O panel using an NT7D61Ax
modem cable. Make sure the modem is connected to the telephone system with
an RJ-11 cable/connector.
If your NAC system is powered up and fully functional, you should see the LED
labelled "TR" light up on the front panel of the modem. If the "TR" LED does not
light up, retry this procedure. If the light still does not appear, contact your
Northern Telecom representative.
Procedure 4-6
Alternative procedure for configuring the UDS 2440 modem via workstation for re-
mote diagnostics
Step Action
1 Connect a workstation to the modem
with a straight through NT1R03Dx or
NT1R03Ex cable.
2 Connect the workstation and the
modem to their power sources.
3 Power up the workstation and the
modem.
If you have a workstation, you can use an alternative method to set up the
UDS 2440 modem for remote diagnostic support. To properly configure the
modem, perform Procedure 4-6.
