8-30 Software reinstallations and upgrades
Procedure 8-1 (continued)
Software reinstallation or upgrade to a NAC 2 system
Step Installer's action and system's response
Connection Port
This field indicates the specific port identifier to which a Meridian MAX node is
connected through the Network Link. To enter the Connection Port, press {PF3},
type the Connection Port number and press {PF3} again or type the Connection Port
number and press {RETURN}.
Remote Login Port
This field indicates the specific port on the NAC system that is connected to a
Meridian MAX node. This connection allows the user to log in to Meridian MAX from
the NAC as a Remote Supervisor. To enter the Remote Login Port, press {PF3}, type
the Remote Login Port and press {PF3} again or type the Remote Login Port and
press {RETURN}.
Remote Login Directory Number
This field indicates the telephone number used to connect the NAC system to a
Meridian MAX node through a modem. This connection allows the user to log in to
Meridian MAX from the NAC as a remote supervisor. To enter the Remote Login
Directory Number, press {PF3}, type the Remote Login Directory Number and press
{PF3} again or type the Remote Login Directory Number and press {RETURN}.
Ntwk Link
This field controls the visibility of the node to the NAC system. When this field is set
to Disabled, the node does not provide information to the NAC, supervisor messages
cannot be transmitted to and from the Meridian MAX node, remote printing cannot
occur, and remote supervisor logins to the Meridian MAX node are prohibited.
When this field is set to Enabled, then the node provides information to the NAC,
supervisor messages are transmitted to and from the Meridian MAX node, remote
printing can occur, and remote supervisor logins to the Meridian MAX node are
permitted.
To select the Network Link, press {PF2}. Move the cursor to the selection and press
{RETURN} or enter the selection number and press {RETURN}.
When you are finished entering information on the NAC Network
Definition/Installation screen, press {F1} and select the 'Save changes and exit'
command.
553-4011-110 Standard 1.0 November 1994
—continued—
