6. NOISE FLOOR

6. NOISE FLOOR

Description

This test checks the noise floor for all the receiver ports of the ENA. The noise
floor is tested by performing load-ended absolute measurements with the test
ports terminated with "Load" devices, 16 times with segment sweep points for
specified frequency ranges. The measurement data is calculated from the RMS
deviation value from the 16 measurement data for each sweep frequency point.

Test equipment

Test Equipment (DSG)
Power Meter (Power Meter 1)
Power Sensor 1 (Power Sensor RF 1)
Power Sensor 2 (Power Sensor RF 2)
Power Sensor 3 (Power Sensor MW 1)
Load (2 or 4 required)
Load (2 or 4 required)*4
3.5 mm cable
3.5 mm (f) to 3.5 mm (f) adapter (2 or
4 required)*4
Type-N (m) to 3.5 mm (f) (2 or 4
required)*4
Keysight E5071C ENA Network Analyzers
1
4
1. The DSG (Device Substitution Group) is listed below the equipment description, if
applicable. These devices are required to be mapped in TME to execute a test.
DSGs require either GPIB communication or are important for dynamic measure-
ment uncertainty calculations. N/A refers to required equipment that is not
mapped as DSGs in TME.
2. Over 8.5 GHz are Options 2D5/2K5/4D5/4K5.
3. Up to 8.5 GHz are Options
230/235/430/435/240/245/440/445/260/265/460/465/280/285/480/485.
4. Two required for 2-port E5071C; four required for 4-port E5071C.
Model Number Over 8.5
GHz
Option
N1914A X
E9340A (Opt H18)
N8482A X
E4413A X
909D X
85032-60018
8121-1834 X
85027-60005 X
1250-2879 X
Up to
8.5 GHz
2 3
Option
X
X
X
X
