  • Page 1 Keysight E5052B Signal Source Analyzer Installation Guide...
  • Page 2 EULA. governed by United States and Declaration of Conformity Keysight shall be under no obligation international copyright laws. to update, revise or otherwise modify Trademark Acknowledgments Declarations of Conformity for this the Software.
  • Page 3 The E5052B complies with INSTALLATION CATEGORY II as well as POLLUTION DEGREE 2 in IEC61010-1. The E5052B is an INDOOR USE product. The LEDs in the E5052B are Class 1 in accordance with IEC60825-1, CLASS 1 LED PRODUCT. • Ground the Instrument To avoid electric shock, the instrument chassis and cabinet must be grounded with the supplied power cable’s grounding prong.
  • Page 4 To avoid the danger of introducing additional hazards, do not install substitute parts or perform unauthorized modifications to the instrument. Return the instrument to a Keysight Technologies Sales and Service Office for service and repair to ensure that safety features are maintained in operational condition.
  • Page 5 Certification Keysight Technologies certifies that this product met its published specifications at the time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institution’s calibration facility or by the calibration facilities of other...
  • Page 6 Safety Summary Safety Symbols Keysight E5052B Signal Source Analyzer...

  • Page 7: Table Of Contents

    Initial Registration of E5052B........
  • Page 8 Factory Recovery ............39 User Recovery (only for HDD Revision NM320 or below) ......52 Keysight E5052B Installation Guide...

  • Page 9: Introduction

    Installation Guide The installation guide (this manual) provides start up setup information when you use the E5052B for the first time and troubleshooting information when the Windows cannot be boot up. Online Help The Online Help provides the information about the measurement operation, programming, built-in VBA, I/O interface This is pre-installed in the E5052B.

  • Page 10: Contents Of This Manual

    This chapter introduces the documentation for Keysight E5052B and the overview of this manual to use this manual efficiently. See this manual first when you use the E5052B for the first time. Chapter 2, “Installation.” This chapter provides information about how to set up the Keysight E5052B.

  • Page 11: Installation

    “Installing Front Handles/Rack Mounting Flanges” on page 16 Shows how to mount the front handles used to transport the E5052B and how to install the flanges needed to install it in a rack. “Connecting the Accessories” on page 19 Provides information for connecting the mouse, keyboard, BNC adaptor to the E5052B.

  • Page 12: Checking The Shipment

    Step 3. By referring to the furnished contents list, check that all packaged items supplied with the analyzer have been provided as per the specified options. Step 4. After checking, if one of the following applies, contact your nearest Keysight Technologies sales and service office.

  • Page 13: Environmental Requirements

    Installation Environmental Requirements Environmental Requirements Set up the E5052B where the following environmental requirements are met. Operating Environments Ensure that the operating environment meets the following requirements. Temperature 10ºC to 40ºC 23ºC  5ºC (< 1ºC deviation from the temperature...

  • Page 14: Ventilation Requirements

    Requirements Back ≥ 180 mm Sides ≥ 60 mm (both right and left) Figure 2-1 Ventilation space at the installation When measuring place the E5052B in a proper position as show in Figure 2-1. Keysight E5052B Signal Source Analyzer...

  • Page 15: Protection Against Electrostatic Discharge (Esd)

    25, the power supply is disconnected by removing the power cable’s connector plug from either the AC outlet or the E5052B unit. When installing the E5052B, ensure that there is sufficient free space around the unit to permit quick disconnection of the plug (from AC outlet or E5052B unit) in case of emergency.

  • Page 16: Installing Front Handles/Rack Mounting Flanges

    Installing Front Handles/Rack Mounting Flanges Installing Front Handles/Rack Mounting Flanges The E5052B can be installed on a workbench or in a rack. This section describes how to install the front handles (Option 1CN) used for moving or transporting the instrument, and how to install the analyzer in an equipment rack as part of a measurement system (Option 1CM: without the handles, Option 1CP: with the handles).

  • Page 17: How To Install The Handle Kit (Option 1Cn)

    Installing Front Handles/Rack Mounting Flanges Figure 2-3 Installing front handle/rack-mount kits How to Install the Handle Kit (Option 1CN) The handle kit is used for transport and relocation of the E5052B. While referring to Figure 2-3, install the handle kit by following these steps.

  • Page 18: How To Install The Rack-Mount Kit (Option 1Cm)

    Step 2. Use the provided screws to mount a rack-mounting flange (4) on each side of the E5052B front panel frame. Step 3. Remove the four bottom feet of the E5052B (lift the bar marked TAB on the inner side of the foot and slide the foot toward the bar).

  • Page 19: Connecting The Accessories

    You need to connect some accessories before use. Connecting Mouse and Keyboard The E5052B allows you to connect Mouse and/or keyboard through USB. USB mouse and keyboard can be connected with the USB ports on the front or rear panels.

  • Page 20: Power Supply

    1. Switched automatically by the E5052B in conformity to the voltage used. Verification and Connection of Power Cable The three-wire power cable attached to the E5052B has one wire serving as a ground. Using this power cable allows the E5052B to be grounded, thereby protecting you against electrical shock from the power outlet.
  • Page 21 Installation Power Supply Figure 2-4 Power cable options Keysight E5052B Signal Source Analyzer...

  • Page 22: Blown Fuses

    Blown fuses If the fuse appears to have blown during operation, this instrument may be subject to failure and must be repaired. Ship the E5052B to the nearest Keysight Technologies Service Center. The product uses the following fuse type: UL/CSA Type, Slow-Blo, 15 A-250 V Do NOT replace the fuse yourself;...

  • Page 23: Starting The E5052B

    Installation Starting the E5052B Starting the E5052B This section describes how to turn on/off the E5052B power and how to cut off the power supply in an emergency. Turning the Power ON and OFF Perform the following steps to turn the power ON or OFF.
  • Page 24 If the power supply is cut off directly by disconnecting the power cable plug from the instrument or the AC outlet, the shutdown process is not carried out and there is a risk of damage to the E5052B’s software or hardware.

  • Page 25: Disconnection From Supply Source

    Removing / Mounting Removable Hard Disk Disconnection from Supply Source The power supply of the E5052B is cut off by disconnecting the plug of the power cable (on either AC outlet side or E5052B side). When it is necessary to disconnect the power supply in order to avoid shock hazards, etc., pull out the...

  • Page 26: Initial Registration Of E5052B

    Initial Registration of E5052B Initial Registration of E5052B When you start up the E5052B at the first time, you need to perform the initial registration for Windows operating system of E5052B. There are three methods of initial registration procedure depending on the...
  • Page 27 I accept this agreement box and click the Next > button (Figure 2-8). Figure 2-8 Windows XP Professional Setup dialog box (1/2) e5071cse1074 Step 4. In the next dialog box, input E5052 in the Name box. Then, click the Next> button (Figure 2-9). Keysight E5052B Signal Source Analyzer...
  • Page 28 Initial Registration of E5052B Figure 2-9 Windows XP Professional Setup dialog box (2/2) E5052 e5052bse1033 Step 5. The E5052B restart automatically. Step 6. The Keysight Recovery Image Setup screen (Figure 2-10) appears. Click OK to proceed. Figure 2-10 Keysight Recovery Image Setup Screen(1/1) Step 7.
  • Page 29 Step 8. A message dialog box appears after the completion of the Recovery Image Setup procedure. The dialog box disappears automatically after a few seconds. Step 9. The E5052B firmware is executed, then the measurement display appears. Keysight E5052B Signal Source Analyzer...

  • Page 30: Windows Vista Business (Hdd Revision: Nm320 Or Below)

    Installation Initial Registration of E5052B Windows Vista Business (HDD Revision: NM320 or below) Step 1. Turn on the E5052B. Step 2. The Windows XP Professional Setup wizard appears. Click the Next > button (Figure 2-12). Figure 2-12 Windows XP Professional Setup wizard e5071cse1073 Step 3.
  • Page 31 Installation Initial Registration of E5052B Figure 2-14 Windows XP Professional Setup dialog box (2/2) E5052 e5052bse1033 Step 5. After a while, the E5052B restarts automatically. Then, the measurement display appears. Keysight E5052B Signal Source Analyzer...

  • Page 32: Windows Xp Pro For Embedded Systems

    Installation Initial Registration of E5052B Windows XP Pro for Embedded Systems Step 1. Turn on the E5052B. Step 2. The screen shown in Figure 2-15 appears. Select Windows XP Professional and press Enter. Figure 2-15 System start up screen in Windows XP Pro for Embedded Systems (1/2) Step 3.
  • Page 33 Step 5. In the License agreement dialog box, select the I accept this agreement box and click the Next > button. Figure 2-18 shows the license agreement dialog box in Windows XP Pro for Embedded Systems. Figure 2-18 Windows XP Pro for Embedded Systems license agreement dialog box Keysight E5052B Signal Source Analyzer...
  • Page 34 Step 6. In the next dialog box, set the date and time for your Windows. Then, click the Next> button as shown in Figure 2-19. Figure 2-19 Date and Time Setting dialog box Step 7. After a while, the E5061B restarts automatically. Keysight E5052B Signal Source Analyzer...

  • Page 35: Online Help

    The Online Help provides the information about the quick start, measurement operation, programming, built-in VBA, I/O interface This is pre-installed in the E5052B. Press [Help] hard key on the front panel to open. Quick Start helps in understanding the E5052B operation quickly.
  • Page 36 Installation Online Help Keysight E5052B Signal Source Analyzer...

  • Page 37: Troubleshooting

    Keysight E5052B Signal Source Analyzer Installation Guide Troubleshooting This chapter describes the troubleshooting during start up and the procedure of the operating system (OS) recovery when the Windows OS has been damaged. Troubleshooting during Startup When you encounter the problem during start up, see Table 3-1.

  • Page 38: System Recovery

    HDD revision. The Windows OS license and HDD revision can be confirmed using the following procedure: Step 1. Check the Windows License label on the rear panel of the E5052B. Step 2. In the E5052B, from Windows Start Menu, click on My Computer.

  • Page 39: Types Of System Recoveries

    HDD Revision: NWxxx or NHxxx Step 1. Connect a keyboard if Windows 10. Step 2. Press the standby switch of the E5052B to turn it on. Step 3. When the screen as shown in the figure below appears, select Instrument Image Recovery System and press [Enter].
  • Page 40 System Recovery Figure 3-1 Instrument Image Recovery System Selection Screen Step 4. In the Keysight Software End User License Agreement dialog box, select the Agree button. Step 5. Type 2 to select Recover the original factory system image option and press [Enter].
  • Page 41 Figure 3-4 System configuration progress screen Step 8. Once the recovery process is completed, completion message prompts. Click OK. The E5052B restarts automatically. Figure 3-5 Recovery completion dialog box Keysight E5052B Signal Source Analyzer...
  • Page 42 Step 2. The boot option is displayed. Use the downward arrow key to select the “Keysight Recovery Solution” and press Enter Step 3. Windows PE starts up and “Keysight Recovery Program” window is displayed. Press 1, and then press Enter.
  • Page 43 Step 5. Caution is displayed. Press 1, and then press Enter. Figure 3-8 Keysight Recovery Program(1/3) Step 6. Recovery function is performed. Step 7. A message box appears after the completion of recovery process. Press any key to continue. Keysight E5052B Signal Source Analyzer...
  • Page 44 Troubleshooting System Recovery Figure 3-9 Keysight Recovery Program(1/4) Step 8. When factory recovery is finished, the E5052B restarts. Step 9. After restart, the screen for initial registration appears. Execute initial registration. For information on the execution procedure, refer to “Windows Vista Business (HDD Revision: NM321 or above)”...
  • Page 45 Step 2. Disconnect all of the USB device from the USB ports. Step 3. Connect the keyboard to the E5052B. Step 4. Press the standby switch of the E5052B to turn it on. Step 5. When the screen as shown in the figure below appears, press of the keyboard.
  • Page 46 The recovery takes a few minutes depending on the amount of data. Figure 3-11 Recover Factory Backup e5052bse1018 Step 8. When the recovery is finished, click OK. The E5052B restarts automatically. Keysight E5052B Signal Source Analyzer...
  • Page 47 Vista Business (HDD Revision: NM320 or below)” on page Step 10. Execute the calibration of the touch screen. Never turn off the power during the system recovery because doing so may cause serious damage to the E5052B. Keysight E5052B Signal Source Analyzer...
  • Page 48 The User back up function is not available. You need a keyboard for this operation. Step 1. Turn ON the E5052B. Step 2. The boot option is displayed. Use the downward arrow key to select the “Keysight Recovery System” and press Enter...
  • Page 49 Step 4. A confirmation message appears. Click OK to continue the process. Figure 3-14 System recovery confirmation screen Step 5. The progress of the system configuration is displayed on the screen. The recovery takes a few minutes depending on the amount of data. Keysight E5052B Signal Source Analyzer...
  • Page 50 Figure 3-15 System configuration progress screen Step 6. Once the recovery process is completed, completion message prompts. Click OK. The E5052B restarts automatically Figure 3-16 Recovery Option confirmation dialog box Step 7. Type 5 to select Exit and Restart the instrument and click OK.
  • Page 51 Step 8. After the restart, execute initial registration. For information on the execution procedure, refer to“Windows XP Pro for Embedded Systems” on page Never turn off the power during the system recovery because doing so may cause serious damage to the E5052B. Keysight E5052B Signal Source Analyzer...

  • Page 52: User Recovery (Only For Hdd Revision Nm320 Or Below)

    Step 1. Close the E5052B application by pressing System > Service Menu > Administrator Menu > Exit E5052B > OK. Step 2. Close all other applications you currently open.
  • Page 53 Troubleshooting System Recovery Step 5. Click Backup e5071cse1125 Step 6. Click Next button. e5071cse1126 Keysight E5052B Signal Source Analyzer...
  • Page 54 Troubleshooting System Recovery Step 7. Select “The entire disk contents or individual partition,” then click Next button. e5071cse1127 Step 8. Select the C drive and F drive. e5052bse1019 Keysight E5052B Signal Source Analyzer...
  • Page 55 D drive. Also, never save the contents of the drive to the C, E or F drive. e5052bse1020 Step 10. Select “Set the options manually” and click Next button. e5071cse1130 Keysight E5052B Signal Source Analyzer...
  • Page 56 Step 11. Select “Backup priority” in the left field and “High” in the right field, then click Next button. e5071cse1131 Step 12. If necessary, input comments and click Next button. The comments can be omitted. e5071cse1132 Keysight E5052B Signal Source Analyzer...
  • Page 57 Troubleshooting System Recovery Step 13. Click Proceed button. e5052bse1021 Step 14. The following screen appears during backup. e5052bse1022 Keysight E5052B Signal Source Analyzer...
  • Page 58 Step 15. The following screen appears when the user backup image was created. Click e5052bse1023 Never turn off the power during creating the user backup image because doing so may cause serious damage to the E5052B. Keysight E5052B Signal Source Analyzer...
  • Page 59 “Procedure to create the user backup image (only available when HDD Revision is NM320 or below)” on page Step 1. Close the E5052B application by pressing System > Service Menu > Exit. Step 2. Close all other applications you currently open.
  • Page 60 Troubleshooting System Recovery Step 6. Click Next button. e5071cse1137 Step 7. Select the saved backup image file, then click Next button. e5052bse1024 Keysight E5052B Signal Source Analyzer...
  • Page 61 Troubleshooting System Recovery Step 8. Select “Restore disks or partitions,” then click Next button. e5071cse1139 Step 9. Select the C drive, then click Next button. e5052bse1025 Keysight E5052B Signal Source Analyzer...
  • Page 62 Troubleshooting System Recovery Step 10. Select the C drive to restore, then click Next button. e5052bse1026 Step 11. Select “Active” and click Next button. e5071cse1145 Keysight E5052B Signal Source Analyzer...
  • Page 63 Troubleshooting System Recovery Step 12. Click Next button. e5052bse1027 Step 13. Select “Yes, I want to assign a logical drive letter to the restored partition.” and click Next button. e5071cse1147 Keysight E5052B Signal Source Analyzer...
  • Page 64 Troubleshooting System Recovery Step 14. Select “Yes, I want to restore another partition or hard disk drive.” then click Next button. e5052bse1077 Step 15. Select the F drive to restore, then click Next button. e5052bse1028 Keysight E5052B Signal Source Analyzer...
  • Page 65 Troubleshooting System Recovery Step 16. Select the F drive to restore, then click Next button. e5052bse1029 Step 17. Select “Logical” and click Next button. e5052bse1078 Keysight E5052B Signal Source Analyzer...
  • Page 66 Troubleshooting System Recovery Step 18. Click Next button. e5052bse1030 Step 19. Select “Yes, I want to assign a logical drive letter to the restored partition,” then click Next button. e5052bse1031 Keysight E5052B Signal Source Analyzer...
  • Page 67 Troubleshooting System Recovery Step 20. Select “No, I do not.” and click Next button. e5052bse1079 Step 21. Select “Set the options manually” and click Next button. e5052bse1080 Keysight E5052B Signal Source Analyzer...
  • Page 68 Troubleshooting System Recovery Step 22. Select “Restoration Priority” in the left field and “High” in the right field, then click Next button. e5052bse1081 Step 23. Click Proceed button. e5052bse1032 Keysight E5052B Signal Source Analyzer...
  • Page 69 Step 24. Click Reboot button. e5052bse1082 Never turn off the power during the recovery of the user backup image because doing so may cause serious damage to the E5052B. Step 25. After boot up, perform “Initial Registration of E5052B” on page 26 Calibration of Touch Screen.
  • Page 70 Troubleshooting System Recovery Keysight E5052B Signal Source Analyzer...
  • Page 71 System Recovery How to Execute Initial registration inspection Windows XP checking the shipment manual contents , 9, power check the power supply disconnecting device Keysight E5063A Installation Guide...
  • Page 72 Index Keysight E5063A Installation Guide...
  • Page 73 This information is subject to change without notice. © Keysight Technologies 2007-2018 Edition 7, February 2018 *E5052-90046* E5052-90046 www.keysight.com...
