  • Page 1 Keysight E5071C ENA Series RF Network Analyzers Installation Guide...
  • Page 2 EULA. governed by United States and Declaration of Conformity Keysight shall be under no obligation international copyright laws. to update, revise or otherwise modify Trademark Acknowledgments Declarations of Conformity for this the Software.

  • Page 3: Safety Summary

    Such noncompliance would also violate safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability for the customer’s failure to comply with these precautions. The E5071C complies with INSTALLATION CATEGORY II as well as POLLUTION DEGREE 2 in IEC61010-1.
  • Page 4 To avoid the danger of introducing additional hazards, do not install substitute parts or perform unauthorized modifications to the instrument. Return the instrument to a Keysight Technologies Sales and Service Office for service and repair to ensure that safety features are maintained in operational condition.

  • Page 5: Safety Symbols

    Certification Keysight Technologies certifies that this product met its published specifications at the time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institution’s calibration facility or by the calibration facilities of other...

  • Page 6: Assistance

    Product maintenance agreements and other customer assistance agreements are available for Keysight Technologies products. For any assistance, contact your nearest Keysight Technologies Sales and Service Office. Addresses are provided at the back of this manual. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 7: Table Of Contents

    Windows XP Pro for Embedded Systems ........28 Windows Vista Business (HDD Revision: CN925 or above) ..... . . 32 Keysight E5071C Installation Guide...
  • Page 8 Factory Recovery ............41 User Recovery (only for HDD Revision CN924 or below) ......53 Keysight E5071C Installation Guide...

  • Page 9: Introduction

    See this manual first when you use the E5071C for the first time. Manuals for E5071C Keysight provides the following three manuals for E5071C. The latest version of all documentations can be downloaded from http://www.keysight.com/find/e5071c-manual.
  • Page 10 E5071C for the first time. Chapter 2, “Installation.” This chapter provides information about how to set up the Keysight E5071C. Chapter 3, “Troubleshooting.” This chapter describes the troubleshooting during start up and the procedure of the operating system (OS) recovery when the Windows OS has been damaged.

  • Page 11: Installation

    Keysight E5071C ENA Series RF Network Analyzers Installation Guide Installation This chapter provides information about how to set up the Keysight E5071C. Contents of this Chapter “Checking the Shipment” on page 12 After you receive the analyzer, check all the items in the packing container.

  • Page 12: Checking The Shipment

    Step 3. By referring to the furnished contents list, check that all packaged items supplied with the analyzer have been provided as per the specified options. Step 4. After checking, if one of the following applies, contact your nearest Keysight Technologies sales and service office.

  • Page 13: Environmental Requirements

    0 to 2,000 m (0 to 6,561 feet) Vibration 0.21 G maximum, 5 Hz to 500 Hz Above environmental requirements are NOT for the specifications and measurement accuracy of the analyzer, but for the operating environment of the analyzer. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 14: Ventilation Requirements

    PORT 1 PORT 2 PORT 3 PORT 4 PROBE POWER + 26 dBm RF 35 VDC Max Avoid Static Discharge CAT e5071cqe2001 Place the E5071C in a proper position as show in Figure 2-1. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 15: Protection Against Electrostatic Discharge (Esd)

    AC outlet or the E5071C unit. When installing the E5071C, ensure that there is sufficient free space around the unit to permit quick disconnection of the plug (from AC outlet or E5071C unit) in case of emergency. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 16: Installing Front Handles/Rack Mounting Flanges

    Rack-mount Kit Rack-mount and Handle Kit Table 2-2 Contents of each option Option Contents Quantity Front Handles Screws Trim Strips Rack-mounting flanges (locking side plate) Screws Rack-mounting flanges (locking side plate) Front Handles Screws Keysight E5071C ENA Series RF Network Analyzers...

  • Page 17: How To Install The Handle Kit (Option 1Cn)

    If the installed front handle becomes damaged, replace it with a new one immediately. A damaged handle can break while moving or lifting the instrument and cause personal injury or damage to the instrument. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 18: How To Install The Rack-Mount Kit (Option 1Cm)

    Step 3. Remove the four bottom feet of the E5071C (lift the bar marked TAB on the inner side of the foot and slide the foot toward the bar). Step 4. Mount the E5071C on the rack. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 19: Connecting The Accessories

    The E5071C allows you to connect Mouse and/or keyboard through USB. USB mouse and keyboard can be connected with the USB ports on the front or rear panels. System Recovery of the E5071C requires the mouse and keyboard before turning on the power. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 20: Power Supply

    24) on the rear panel of the E5071C and a three-wire power outlet with the grounding prong firmly connected in the ground slot. Use the supplied power cable with grounding wire to securely ground the E5071C. Power cord information is available at http://www.keysight.com/find/powercords. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 21: Blown Fuses

    Blown Fuses Blown Fuses If the fuse appears to have blown during operation, this instrument may be subject to failure and must be repaired. For any assistance, contact Keysight Technologies Customer contact center. The product uses the following fuse type: Option 230/235/240/245/280/285/430/435/440/445/480/485: UL/CSA Type, Slow-Blo, 6.3 A-250 Vac.

  • Page 22: Starting The E5071C

    Step 2. If the standby switch ( ) in the lower-left part of the front panel is in the depressed ( ) position, press it to put it in the popped up position ( Keysight E5071C ENA Series RF Network Analyzers...
  • Page 23 If the power supply is cut off directly by disconnecting the power cable plug from the instrument or the AC outlet, the shutdown process is not carried out and there is a risk of damage to the E5071C’s software or hardware. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 24: Disconnection From Supply Source

    Immediate Disconnection of Power Cable in Case of Emergency” on page 15. When turning the power OFF under normal circumstances, always follow the methods described in “Turning the Power ON and OFF” on page 22 Keysight E5071C ENA Series RF Network Analyzers...

  • Page 25: Removing / Mounting Removable Hard Disk (For Option 017 User)

    Removing / Mounting Removable Hard Disk (For Option 017 User) Removing / Mounting Removable Hard Disk (For Option 017 User) For details of removing / mounting removable hard disk, refer to the following website http://ena.support.keysight.com/e5071c/manuals/webhelp/eng/ Keysight E5071C ENA Series RF Network Analyzers...

  • Page 26: Initial Registration Of E5071C

    In this case, follow the instruction to return to the previous registration screen. Failure to comply with the illustrated procedures may cause serious damage to the E5071C. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 27: Windows Embedded Standard 7 / 10

    The license agreement dialog box as shown in Figure 2-11 appears. Click “Accept” if you agree it. Figure 2-8 License Agreement (Example for Windows 7) Step 3. After a while, the E5071C measurement application starts automatically. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 28: Windows Xp Pro For Embedded Systems

    Select Windows XP Professional and press Enter. Figure 2-9 System start up screen in Windows XP Pro for Embedded Systems (1/2) Step 3. The screen as shown in Figure 2-10 appears. Press Enter. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 29 Installation Initial Registration of E5071C Figure 2-10 System start up screen in Windows XP Pro for Embedded Systems (2/2) Keysight E5071C ENA Series RF Network Analyzers...
  • Page 30 Next > button. Figure 2-12 shows the license agreement dialog box in Windows XP Pro for Embedded Systems. Figure 2-12 Windows XP Pro for Embedded Systems license agreement dialog box Keysight E5071C ENA Series RF Network Analyzers...
  • Page 31 Step 6. In the next dialog box, set the date and time for your Windows. Then, click the Next > button as show in Figure 2-13. Figure 2-13 Date and Time Setting dialog box Step 7. After a while, the E5071C restarts automatically. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 32: Windows Vista Business (Hdd Revision: Cn925 Or Above)

    E5071C therefore connect the mouse and the keyboard before turning on the power. Step 1. Turns on the E5071C. Step 2. The Windows XP Professional Setup wizard appears. Click the Next > button (Figure 2-14). Figure 2-14 Windows XP Professional Setup wizard e5071cse1073 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 33 (Figure 2-16). Figure 2-16 Windows XP Professional Setup dialog box (2/2) e5071cse1075 Step 5. The E5071C restart automatically. Step 6. The Keysight Recovery Image Setup screen (Figure 2-17) appears. Click OK to proceed. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 34 Step 2. Select Properties. The System Properties dialog box appears. Step 3. Select Hardware tab. Step 4. Click Device Manager. The Device Manager dialog box appears. Step 5. Select Ports (COM & LPT). Keysight E5071C ENA Series RF Network Analyzers...
  • Page 35 Step 6. Check if two Communication Port (COM1) are displayed. Step 7. Right click and select Unistall for both the COM1 ports. Step 8. The Confirm Device Removal message box appears. Click OK. Step 9. Reboot the instrument. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 36: Windows Vista Business (Hdd Revision: Cn924 Or Below)

    Next > button (Figure 2-15). Figure 2-20 Windows XP Professional Setup dialog box (1/2) e5071cse1074 Step 4. In the next dialog box, input agena in the Name box. Then, click the Next> button (Figure 2-16). Keysight E5071C ENA Series RF Network Analyzers...
  • Page 37 Installation Initial Registration of E5071C Figure 2-21 Windows XP Professional Setup dialog box (2/2) e5071cse1075 Step 5. After a while, the E5071C restart automatically. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 38: Online Help

    VBA, I/O interface. This is pre-installed in the E5071C. Press [Help] hard key on the front panel to open. Quick Start helps in understanding the E5071C operation quickly. The latest version of online help is available at http://ena.support.keysight.com/e5071c/manuals/webhelp/eng/. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 39: Troubleshooting

    Keysight E5071C ENA Series RF Network Analyzers Installation Guide Troubleshooting This chapter describes the troubleshooting during start up and the procedure of the operating system (OS) recovery when the Windows OS has been damaged. Troubleshooting during Startup When you encounter the problem during start up, see Table 3-1.

  • Page 40: System Recovery

    Strictly follow the steps described below. If you do any operation other than the following steps, the system may not be recovered. 1. If the hard disk failed and has been replaced after purchase, the state when the replacement was performed is recovered. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 41: Types Of System Recoveries

    Files you created using the save function (files in the D drive) are not affected, but we recommend backing them up before executing system recovery for precautionary purposes. For more information on backup, refer to “Backing Up the Data” as described in E5071C Online Help. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 42 Image Recovery System and press [Enter]. Figure 3-1 Instrument Image Recovery System Selection Screen Step 4. In the Keysight Software End User License Agreement dialog box, select the Agree button. Step 5. Type 2 to select Recover the original factory system image option and press [Enter].
  • Page 43 Figure 3-4 System configuration progress screen Step 8. Once the recovery process is completed, completion message prompts. Click OK. The E5071C restarts automatically. Figure 3-5 Recovery completion dialog box Keysight E5071C ENA Series RF Network Analyzers...
  • Page 44 Step 2. The boot option is displayed. Use the downward arrow key to select the “Keysight Recovery Solution” and press Enter Step 3. Windows PE starts up and “Keysight Recovery Program” window is displayed. Press 1, and then press Enter.
  • Page 45 Step 5. Caution is displayed. Press 1, and then press Enter. Figure 3-8 Keysight Recovery Program(1/3) Step 6. Recovery function is performed. Step 7. A message box appears after the completion of recovery process. Press any key to continue. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 46 For information on the execution procedure, refer to “Windows Vista Business (HDD Revision: CN925 or above)” on page If the touch screen does not work after System Recovery, refer to “Reconfiguring Touch Panel Settings” on page 34 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 47 Step 5, if the E5071C freezes with the cursor does not blink, turn the off and remove unnecessary USB devices. Then, replace the keyboard with a PS/2 keyboard to execute the process again. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 48 Step 7. A confirmation dialog box is displayed. Push the enter to select Yes to start the recovery of the factory backup. The recovery takes a few minutes depending on the amount of data. Figure 3-11 Recover Factory Backup e5071cse1034 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 49 Vista Business (HDD Revision: CN924 or below)” on page Step 10. Execute the calibration of the touch screen. Never turn off the power during the system recovery because doing so may cause serious damage to the E5071C. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 50 Step 2. The boot option is displayed. Use the downward arrow key to select the “Keysight Recovery Solution” and press Enter Figure 3-12 Keysight Recovery System selection screen After several seconds, the next screen appears automatically even if you do not press any key. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 51 Step 4. A confirmation message appears. Click OK to continue the process. Figure 3-14 System recovery confirmation screen Step 5. The progress of the system configuration is displayed on the screen. The recovery takes a few minutes depending on the amount of data. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 52 Step 7. After the restart, execute initial registration. For information on the execution procedure, refer to “Windows XP Pro for Embedded Systems” on page Never turn off the power during the system recovery because doing so may cause serious damage to the E5071C. Keysight E5071C ENA Series RF Network Analyzers...

  • Page 53: User Recovery (Only For Hdd Revision Cn924 Or Below)

    Step 2. Close all other applications you currently open. Step 3. From the Windows start menu, select All Programs > Acronis > Acronis True Image. Step 4. Click “No, Thanks” button. Figure 3-17 Recover User Backup e5071cse1080 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 54 Troubleshooting System Recovery Step 5. Click Backup e5071cse1125 Step 6. Click Next button. e5071cse1126 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 55 Troubleshooting System Recovery Step 7. Select “The entire disk contents or individual partition,” then click Next button. e5071cse1127 Step 8. Select the C drive and D drive. e5071cse1128 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 56 E drive. Also, never save the contents of the drive to the C, D or F drive. e5071cse1129 Step 10. Select “Set the options manually” and click Next button. e5071cse1130 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 57 Step 11. Select “Backup priority” in the left field and “High” in the right field, then click Next button. e5071cse1131 Step 12. If necessary, input comments and click Next button. The comments can be omitted. e5071cse1132 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 58 Troubleshooting System Recovery Step 13. Click Proceed button. e5071cse1133 Step 14. The following screen appears during backup. e5071cse1134 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 59 Step 15. The following screen appears when the user backup image was created. Click e5071cse1135 Never turn off the power during creating the user backup image because doing so may cause serious damage to the E5071C. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 60 Step 2. Close all other applications you currently open. Step 3. From the Windows start menu, select All Programs > Acronis > Acronis True Image. Step 4. Click “No, Thanks” button. e5071cse1080 Step 5. Click Recovery. e5071cse1136 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 61 Troubleshooting System Recovery Step 6. Click Next button. e5071cse1137 Step 7. Select the saved backup image file, then click Next button. e5071cse1138 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 62 Troubleshooting System Recovery Step 8. Select “Restore disks or partitions,” then click Next button. e5071cse1139 Step 9. Select the C drive, then click Next button. e5071cse1143 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 63 Troubleshooting System Recovery Step 10. Select the C drive to restore, then click Next button. e5071cse1144 Step 11. Select “Active” and click Next button. e5071cse1145 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 64 Troubleshooting System Recovery Step 12. Click Next button. e5071cse1146 Step 13. Select “Yes, I want to assign a logical drive letter to the restored partition” and click Next button. e5071cse1147 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 65 System Recovery Step 14. Select “Yes, I want to restore another partition or hard disk drive,” then click Next button. e5071cse1148 Step 15. Select the D drive to restore, then click Next button. e5071cse1149 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 66 Troubleshooting System Recovery Step 16. Select the D drive to restore, then click Next button. e5071cse1150 Step 17. Select “Logical” and click Next button. e5071cse1151 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 67 Troubleshooting System Recovery Step 18. Click Next button. e5071cse1152 Step 19. Select “Yes, I want to assign a logical drive letter to the restored partition,” then click Next button. e5071cse1153 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 68 Troubleshooting System Recovery Step 20. Select “No, I do not.” and click Next button. e5071cse1154 Step 21. Select “Set the options manually” and click Next button. e5071cse1155 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 69 Troubleshooting System Recovery Step 22. Select “Restoration Priority” in the left field and “High” in the right field, then click Next button. e5071cse1156 Step 23. Click Proceed button. e5071cse1157 Keysight E5071C ENA Series RF Network Analyzers...
  • Page 70 Never turn off the power during the recovery of the user backup image because doing so may cause serious damage to the E5071C. Step 25. After boot up, perform “Initial Registration of E5071C” on page 26 Calibration of the Touch Screen. Keysight E5071C ENA Series RF Network Analyzers...
  • Page 71 Option 1E5 power check the power supply disconnecting device disconnection from supply source power cable options shutdown verification and connection of power cable rack-mount and handle kit Keysight E5071C Installation Guide...
  • Page 72 Index Keysight E5071C Installation Guide...
  • Page 73 This information is subject to change without notice. © Keysight Technologies 2006-2018 Edition 10, March 2018 *E5071-90080* E5071-90080 www.keysight.com...
