Introduction

1 Introduction

1.1 Software Version

Programming Guide
Software version: 7.11
This Programming Guide can be used for all FC 300 frequency
converters with software version 7.11.
The software version number can be seen from
parameter 15-43 Software Version.
Table 1.1 Software Version

1.2 Approvals

1.3 Symbols

The following symbols are used in this manual.
WARNING
Indicates a potentially hazardous situation which could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which could
result in minor or moderate injury. It may also be used
to alert against unsafe practices.
NOTICE
Indicates important information, including situations that
may result in damage to equipment or property.
1.3.1 Abbreviations
60° AVM 60° Asynchronous Vector Modulation
A Ampere/AMP
AC Alternating current
AD Air discharge
AI Analog Input
AMA Automatic Motor Adaptation
AWG American wire gauge
°C Degrees Celsius
CD Contant discharge
®
VLT AutomationDrive FC 301/302 Programming Guide
CM
CT
DC
DI
DM
D-TYPE
EMC
ETR
f
JOG
f
M
f
MAX
f
MIN
f
M,N
FC
g
Hiperface
hp
HTL
Hz
I
INV
I
LIM
I
M,N
I
VLT,MAX
I
VLT,N
kHz
LCP
lsb
m
mA
MCM
MCT
mH
min
ms
msb
η
VLT
nF
NLCP
Nm
n
s
On-line/Off-line
Parameters
MG33MI02 - Rev. 2013-11-20
Common mode
Constand Torque
Direct current
Digital Input
Differential mode
Drive Dependent
Electro Magnetic Compatibility
Electronic Thermal Relay
Motor frequency when jog function is
activated
Motor frequency
The maximum output frequency the frequency
converter applies on its output
The minimum motor frequency from
frequency converter
Nominal motor frequency
Frequency converter
Gram
® ®
Hiperface is a registered trademark by
Stegmann
Horsepower
HTL encoder (10-30 V) pulses - High-voltage
Transistor Logic
Hertz
Rated Inverter Output Current
Current limit
Nominal motor current
The maximum output current
The rated output current supplied by the
frequency converter
Kilohertz
Local Control Panel
Least significant bit
Meter
Milliampere
Mille Circular Mil
Motion Control Tool
Millihenry Inductance
Minute
Millisecond
Most significant bit
Efficiency of the frequency converter defined
as ratio between power output and power
input
Nanofarad
Numerical Local Control Panel
Newton Meters
Synchronous Motor Speed
Changes to on-line parameters are activated
immediately after the data value is changed.
1 1
