Parameter Descriptions
NOTICE
Options [4]-[9] are only available when the MCB 112 PTC
Thermistor Card is connected.
NOTICE
When Auto Reset/Warning is selected the frequency
converter opens up for automatic restart.
Function No. PTC
No Function [0] -
Safe Stop Alarm [1]* -
Safe Stop Warning [3] -
PTC 1 Alarm [4] PTC 1 Safe Stop
[A71]
PTC 1 Warning [5] PTC 1 Safe Stop
[W71]
PTC 1 & Relay A [6] PTC 1 Safe Stop
[A71]
PTC 1 & Relay W [7] PTC 1 Safe Stop
[W71]
PTC 1 & Relay A/W [8] PTC 1 Safe Stop
[A71]
PTC 1 & Relay W/A [9] PTC 1 Safe Stop
[W71]
Table 3.18 Overview of Functions, Alarms and Warnings
W means warning and A means alarm. For further information, see
Alarms and Warnings in section Troubleshooting in the Design Guide
or the Operating Instructions
A dangerous failure related to Safe Torque Off issues
Alarm: Dangerous Failure [A72].
Refer to Table 5.1.
5-20 Terminal X46/1 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
5-21 Terminal X46/3 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
5-22 Terminal X46/5 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
®
VLT AutomationDrive FC 301/302 Programming Guide
5-23 Terminal X46/7 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-24 Terminal X46/9 Digital Input
Option:
[0] No operation This parameter is active when option module
*
Relay
-
Safe Stop [A68]
Safe Stop [W68]
5-25 Terminal X46/11 Digital Input
-
Option:
[0] No operation This parameter is active when option module
*
-
Safe Stop [A68]
5-26 Terminal X46/13 Digital Input
Safe Stop [W68]
Option:
Safe Stop [W68]
[0] No operation This parameter is active when option module
*
Safe Stop [A68]
3.7.3 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
parameter 5-01 Terminal 27 Mode, and set the I/O function
for terminal 29 in parameter 5-02 Terminal 29 Mode.
NOTICE
These parameters cannot be adjusted while the motor is
running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready /
remote
control
[4] Enable / no
warning
MG33MI02 - Rev. 2013-11-20
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Default for all digital outputs and relay
outputs
The control card is ready. E.g.: Feedback
from a frequency converter where the
control is supplied by an external 24 V
(MCB 107) and the main power to the unit
is not detected.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in [Auto On] mode.
Ready for operation. No start or stop
command is been given (start/disable). No
warnings are active.
3 3
