Troubleshooting
Bit Hex Dec Alarm Word
16 00010000 65536 Live Zero Error
(A2)
17 00020000 131072 Internal Fault
(A38)
18 00040000 262144 Brake Overload
(A26)
19 00080000 524288 U phase Loss
(A30)
20 00100000 1048576 V phase Loss
(A31)
21 00200000 2097152 W phase Loss
(A32)
22 00400000 4194304 Fieldbus Fault
(A34)
23 00800000 8388608 24 V Supply
Low (A47)
24 01000000 16777216 Mains Failure
(A36)
25 02000000 33554432 1.8V Supply
Low (A48)
26 04000000 67108864 Brake Resistor
(A25)
27 08000000 134217728 Brake IGBT
(A27)
28 10000000 268435456 Option Change
(A67)
29 20000000 536870912 Drive Initialised
(A80)
30 40000000 1073741824 Safe Stop (A68) PTC Thermi-stor
31 80000000 2147483648 Mech. brake
low (A63)
Table 5.3 Description of Alarm Word, Warning Word and Extended Status Word
The alarm words, warning words and extended status words can be read out via serial bus or optional fieldbus for
diagnostics. See also parameter 16-94 Ext. Status Word.
WARNING 1, 10 Volts low
The control card voltage is below 10 V from terminal 50.
Remove some of the load from terminal 50, as the 10 V
supply is overloaded. Max. 15 mA or minimum 590 Ω.
A short circuit in a connected potentiometer or improper
wiring of the potentiometer can cause this condition.
®
VLT AutomationDrive FC 301/302 Programming Guide
Alarm Word 2 Warning
Word
reserved Live Zero Error
(W2)
KTY error 10V Low (W1)
Fans error Brake Overload
(W26)
ECB error Brake Resistor
(W25)
Hoist Brake IGBT
mechanical (W27)
brake (A22)
reserved Speed Limit
(W49)
reserved Fieldbus Fault
(W34)
reserved 24V Supply
Low (W47)
reserved Mains Failure
(W36)
Current Limit Current Limit
(A59) (W59)
Motor Rota-ting Low Temp
Unexpectedly (W66)
(A122)
reserved Voltage Limit
(W64)
reserved Encoder loss
(W90)
Encoder loss Output freq.
(A90) lim. (W62)
Safe Stop
(A74) (W68)
Dangerous Extended
failure (A72) Status Word
Troubleshooting
MG33MI02 - Rev. 2013-11-20
Warning Extended
Word 2 Status Word
AC Brake
KTY Warn Password Timelock
number of allowed
password trials exceeded
- timelock active
Fans Warn Password Protection
0-61 = ALL_NO_ACCESS
OR BUS_NO_ACCESS OR
BUS_READONLY
ECB Warn Reference High
reference > 4-55
Hoist Reference Low
mechanical reference < 4-54
brake (W22)
reserved Local Reference
reference site = REMOTE -
> auto on pressed &
active
reserved Protection mode notifi-
cation
reserved Unused
reserved Unused
reserved Unused
reserved Unused
reserved Unused
reserved Unused
BackEMF too Unused
High
PTC Thermi- Unused
stor (W74)
Protection Mode
Remove the wiring from terminal 50. If the
warning clears, the problem is with the wiring. If
the warning does not clear, replace the control
card.
Extended
Status Word
2
Jog
Start Request
Start
5 5
Start Applied
Start delay
Sleep
Sleep Boost
Running
Drive Bypass
Fire Mode
External
Interlock
Firemode
Limit Exceed
Flying Start
active
