Parameter Descriptions
13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
set in parameter 4-50 Warning Current
Low to parameter 4-53 Warning Speed
High.
[4] On reference The motor is running on reference.
[5] Torque limit The torque limit, set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode, has been exceeded.
[6] Current Limit The motor current limit, set in
parameter 4-18 Current Limit, has been
exceeded.
[7] Out of current The motor current is outside the range
range set in parameter 4-18 Current Limit.
[8] Below I low The motor current is lower than set in
parameter 4-50 Warning Current Low.
[9] Above I high The motor current is higher than set in
parameter 4-51 Warning Current High.
[10] Out of speed The speed is outside the range set in
range parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
[11] Below speed The output speed is lower than the
low setting in parameter 4-52 Warning Speed
Low.
[12] Above speed The output speed is higher than the
high setting in parameter 4-53 Warning Speed
High.
[13] Out of feedb. The feedback is outside the range set in
range parameter 4-56 Warning Feedback Low
and parameter 4-57 Warning Feedback
High.
[14] Below feedb. The feedback is below the limit set in
low parameter 4-56 Warning Feedback Low.
[15] Above feedb. The feedback is above the limit set in
high parameter 4-57 Warning Feedback High.
[16] Thermal The thermal warning turns on when the
warning temperature exceeds the limit in the
motor, the frequency converter, the
brake resistor or the thermistor.
[17] Mains out of The mains voltage is outside the
range specified voltage range.
[18] Reversing The output is high when the frequency
converter is running counter clockwise
(the logical product of the status bits
"running" AND "reverse").
[19] Warning A warning is active.
[20] Alarm (trip) A (trip) alarm is active.
®
VLT AutomationDrive FC 301/302 Programming Guide
13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
[21] Alarm (trip lock) A (Trip lock) alarm is active.
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
MG33MI02 - Rev. 2013-11-20
Function:
Use the result of comparator 0.
Use the result of comparator 1.
Use the result of comparator 2.
Use the result of comparator 3.
Use the result of logic rule 0.
Use the result of logic rule 1.
Use the result of logic rule 2.
Use the result of logic rule 3.
Use the result of digital input 18.
Use the result of digital input 19.
Use the result of digital input 27.
Use the result of digital input 29.
Use the result of digital input 32.
Use the result of digital input 33.
A start command is issued.
A stop command (Jog, Stop, Qstop,
Coast) is issued – and not from the SLC
itself.
A reset is issued
An Auto reset is performed.
[OK] is pressed. Only available on the
graphical LCP.
[Reset] is pressed. Only available on the
graphical LCP.
[◄] is pressed. Only available on the
graphical LCP.
[►] is pressed. Only available on the
graphical LCP.
▲
[ ] is pressed. Only available on the
graphical LCP.
▼
[ ] is pressed. Only available on the
graphical LCP.
Use the result of comparator 4.
Use the result of comparator 5.
Use the result of logic rule 4.
Use the result of logic rule 5.
