Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1675] Analog In X30/11
[1676] Analog In X30/12
3 3
[1677] Analog Out X30/8
[mA]
[1678] Analog Out X45/1
[mA]
[1679] Analog Out X45/3
[mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW Extended fieldbus communication
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1687] Bus Readout Alarm/
Warning
[1689] Configurable
Alarm/Warning
Word
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1836] Analog Input X48/2
[mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
[1890] Process PID Error
[1891] Process PID Output
[1892] Process PID
Clamped Output
[1893] Process PID Gain
Scaled Output
[3019] Wobble Delta Freq.
Scaled
30
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Actual value at input X30/11 either
as reference or protection value.
Actual value at input X30/12 either
as reference or protection value.
Actual value at output X30/8 in
mA. Use parameter 6-60 Terminal
X30/8 Output to select the value to
be shown.
Control word (CTW) received from
the Bus Master.
Main reference value sent with
control word from the Bus Master.
option status word.
Control word (CTW) received from
the Bus Master.
Status word (STW) sent to the Bus
Master.
One or more alarms in a hex code.
One or more alarms in a hex code.
One or more warnings in a hex
code.
One or more warnings in a hex
code.
One or more status conditions in a
hex code.
MG33MI02 - Rev. 2013-11-20
0-20 Display Line 1.1 Small
Option: Function:
[3110] Bypass Status Word
[3111] Bypass Running
Hours
[3401] PCD 1 Write to
MCO
[3402] PCD 2 Write to
MCO
[3403] PCD 3 Write to
MCO
[3404] PCD 4 Write to
MCO
[3405] PCD 5 Write to
MCO
[3406] PCD 6 Write to
MCO
[3407] PCD 7 Write to
MCO
[3408] PCD 8 Write to
MCO
[3409] PCD 9 Write to
MCO
[3410] PCD 10 Write to
MCO
[3421] PCD 1 Read from
MCO
[3422] PCD 2 Read from
MCO
[3423] PCD 3 Read from
MCO
[3424] PCD 4 Read from
MCO
[3425] PCD 5 Read from
MCO
[3426] PCD 6 Read from
MCO
[3427] PCD 7 Read from
MCO
[3428] PCD 8 Read from
MCO
[3429] PCD 9 Read from
MCO
[3430] PCD 10 Read from
MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded
Position
[3452] Actual Master
Position
[3453] Slave Index
Position
