Parameter Descriptions
6-62 Terminal X30/8 Max. Scale
Range: Function:
100 [0 - Scales the maximum output of the selected
% 200 analog signal on terminal X30/8. Scale the value
*
%] to the desired maximum value of the current
signal output. Scale the output to give a lower
current than 20 mA at full scale or 20 mA at an
output below 100% of the maximum signal value.
If 20 mA is the desired output current at a value
between 0 - 100% of the ful-scale output,
program the percentage value in the parameter,
i.e. 50% = 20 mA. If a current between 4 and 20
mA is desired at maximum output (100%),
calculate the percentage value as follows:
20 mA / desired maximum current x 100%
20 − 4
i . e . 10 mA :
10
6-63 Terminal X30/8 Bus Control
Range: Function:
0 % [0 - 100 %] Holds the level of Output X30/8 if controlled
*
by bus.
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0 % [0 - 100 Holds the preset level of Output X30/8.
*
%] In case of a bus timeout and a timeout
function is selected in parameter 6-60 Terminal
X30/8 Output, the output is preset to this level.
3.8.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for
analog output 3, Terminal X45/1 and X45/2. Analog
outputs are current outputs: 0/4–20 mA. Resolution on
analog output is 11 bit.
6-70 Terminal X45/1 Output
Option: Function:
Select the function of Terminal X45/1 as an
analog current output.
[0] No operation When no signal on the analog output.
[52] MCO 305 0-20
mA
[53] MCO 305 4-20
mA
[100] Output 0 Hz = 0 mA; 100 Hz = 20 mA.
frequency
0-20 mA
[101] Reference Parameter 3-00 Reference Range [Min - Max]
0-20 mA 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max -
Max] -100% = 0 mA; 0% = 10 mA; +100%
= 20 mA
[102] Feedback
®
VLT AutomationDrive FC 301/302 Programming Guide
x 100 = 160%
MG33MI02 - Rev. 2013-11-20
6-70 Terminal X45/1 Output
Option: Function:
[103] Motor current Value is taken from parameter 16-37 Inv.
0-20 mA Max. Current. Inverter max. current (160%
current) is equal to 20 mA.
Example: Inverter norm current (11 kW) =
24 A. 160% = 38.4 A. Motor norm current
= 22 A Read-out 11.46 mA.
mA x 22 A
20
A
38.4
In case the norm motor current is equal to
20 mA, the output setting of
parameter 6-52 Terminal 42 Output Max
Scale is:
IVLT Max x 100
IMotor Norm
[104] Torque rel to The torque setting is related to setting in
lim 0-20 mA parameter 4-16 Torque Limit Motor Mode
[105] Torque rel to The torque is related to the motor torque
rated motor setting.
torque 0-20
mA
[106] Power 0-20 Taken from parameter 1-20 Motor Power
mA [kW].
[107] Speed 0-20 Taken from parameter 3-03 Maximum
mA Reference. 20 mA = value in
parameter 3-03 Maximum Reference
[108] Torque ref. Torque reference related to 160% torque.
0-20 mA
[109] Max Out Freq In relation to parameter 4-19 Max Output
0-20 mA Frequency.
[130] Output freq. 0 Hz = 4 mA, 100 Hz = 20 mA
4-20 mA
[131] Reference Parameter 3-00 Reference Range [Min-Max]
4-20 mA 0% = 4 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max-Max]
-100% = 4 mA; 0% = 12 mA; +100% = 20
mA
[132] Feedback 4-20
mA
[133] Motor cur. Value is taken from parameter 16-37 Inv.
4-20 mA Max. Current. Inverter max. current (160%
current) is equal to 20 mA.
Example: Inverter norm current (11 kW) =
24 A. 160% = 38.4 A. Motor norm current
= 22 A Read-out 11.46 mA.
16 mA x 22 A
38.4 A
In case the norm motor current is equal to
20 mA, the output setting of
parameter 6-52 Terminal 42 Output Max
Scale is:
IVLT Max x 100
IMotor Norm
[134] Torque% lim. The torque setting is related to setting in
4-20 mA parameter 4-16 Torque Limit Motor Mode.
[135] Torque% nom The torque setting is related to the motor
4-20 mA torque setting.
= 11.46 mA
38.4 x 100
= = 175%
22
mA
= 9.17
x 100
38.4
= = 175%
22
