Parameter Descriptions
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option:
[70] SL Time-out 3 Smart Logic Controller timer 3 is
timed out.
[71] SL Time-out 4 Smart Logic Controller timer 4 is
timed out.
[72] SL Time-out 5 Smart Logic Controller timer 5 is
timed out.
[73] SL Time-out 6 Smart Logic Controller timer 6 is
timed out.
[74] SL Time-out 7 Smart Logic Controller timer 7 is
timed out.
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 164 ATEX ETR
cur.lim.alarm is active, the output
is 1.
[91] ATEX ETR cur. alarm Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 166 ATEX ETR
freq.lim.alarm is active, the output
is 1.
[92] ATEX ETR freq. Selectable, if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the
output is 1.
[93] ATEX ETR freq. alarm Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the warning 165 ATEX ETR
freq.lim.warning is active, the
output is 1.
[94] RS Flipflop 0 See parameter group 13-1*
Comparators
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
MG33MI02 - Rev. 2013-11-20
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option: Function:
[95] RS Flipflop 1 See parameter group 13-1*
Comparators
[96] RS Flipflop 2 See parameter group 13-1*
Comparators
[97] RS Flipflop 3 See parameter group 13-1*
Comparators
[98] RS Flipflop 4 See parameter group 13-1*
Comparators
[99] RS Flipflop 5 See parameter group 13-1*
Comparators
[100] RS Flipflop 6 See parameter group 13-1*
Comparators
[101] RS Flipflop 7 See parameter group 13-1*
Comparators
[102] Relay 1
[103] Relay 2
[104] Relay 3 X47/MCB 113
[105] Relay 4 X47/MCB 113
[106] Relay 5 X47/MCB 113
[107] Relay 6 X47/MCB 113
[108] Relay 7 X34/MCB 105
[109] Relay 8 X34/MCB 105
[110] Relay 9 X34/MCB 105
13-03 Reset SLC
Option: Function:
[0] Do not reset Retains programmed settings in all parameter
SLC group 13-** Smart Logic Control.
[1] Reset SLC Resets all parameters in parameter group 13-
** Smart Logic Control to default settings.
