Parameter Descriptions
[123] Start
command
active
[124] Running
reverse
3 3
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
[152] ATEX ETR
freq. alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR
freq. warning
[188] AHF Capacitor
Connect
[189] External fan
control
[190] Safe Function
active
[191] Safe Opt.
Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
88
®
VLT AutomationDrive FC 301/302 Programming Guide
Output is high when there is an active
Start command (i.e. via digital input bus
connection or Hand on or Auto on), and
no Stop or Start command is active.
Output is high when the frequency
converter is running counter clockwise (the
logical product of the status bits 'running'
AND 'reverse').
Output is high when the frequency
converter is in Hand On mode (as
indicated by the LED light above [Hand
on]).
Output is high when the frequency
converter is in Hand On mode (as
indicated by the LED light above Auto On).
Selectable, if parameter 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or [21]
Advanced ETR. If the alarm 164 ATEX ETR
cur.lim.alarm is active, the output is 1.
Selectable, if parameter 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or [21]
Advanced ETR. If the alarm 166 ATEX ETR
freq.lim.alarm is active, the output is 1.
Selectable, ifparameter 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or [21]
Advanced ETR. If the alarm 163 ATEX ETR
cur.lim.warning is active, the output is 1.
Selectable, if parameter 1-90 Motor Thermal
Protection is set to [20] ATEX ETR or [21]
Advanced ETR. If the warning 165 ATEX ETR
freq.lim.warning is active, the output is 1.
The capacitors are turned on at 20%
(hysteresis of 50% gives an interval of 10%
- 30%). The capacitors are disconnected
below 10%. The off delay is 10 s and
restarts if the nominal power goes above
10% during the delay. Parameter 5-80 AHF
Cap Reconnect Delay is used to guarantee a
minimum off-time for the capacitors.
The internal logics for the internal fan
control is transferred to this output to
make it possible to control an external fan
(relevant for HP duct cooling).
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
5-30 Terminal 27 Digital Output
Option:
[0] No operation Functions are described under parameter
*
5-31 Terminal 29 Digital Output
Option:
[0] No operation Functions are described under parameter
*
5-32 Term X30/6 Digi Out (MCB 101)
Option:
[0] No operation
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready,no TW
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[33] Safe stop active
[38] Motor feedback error
[39] Tracking error
[40] Out of ref range
MG33MI02 - Rev. 2013-11-20
Function:
group 5-3* Digital Outputs
Function:
group 5-3* Digital Outputs
This parameter is applicable for FC 302 only
Function:
This parameter is active when
option module MCB 101 is
mounted in the frequency
converter. Functions are described
under parameter group 5-3*
Digital Outputs
