Parameter Descriptions
13-01 Start Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
[76] Digital input
3 3
x30/2
[77] Digital input
x30/3
[78] Digital input
x30/4
[79] Digital input
x46/1
[80] Digital input
x46/3
[81] Digital input
x46/5
[82] Digital input
x46/7
[83] Digital input
x46/9
[84] Digital input
x46/11
[85] Digital input
x46/13
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
126
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Use the value of x30/2 (MCB 101 GPIO)
Use the value of x30/3 (MCB 101 GPIO)
Use the value of x30/4 (MCB 101 GPIO)
Use the value of x46/1 (MCB 113 Ext.
Relay Card)
Use the value of x46/3 (MCB 113 Ext.
Relay Card)
Use the value of x46/5 (MCB 113 Ext.
Relay Card)
Use the value of x46/7 (MCB 113 Ext.
Relay Card)
Use the value of x46/9 (MCB 113 Ext.
Relay Card)
Use the value of x46/11 (MCB 113 Ext.
Relay Card)
Use the value of x46/13 (MCB 113 Ext.
Relay Card)
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
See parameter group 13-1* Comparators
Function:
For descriptions [0]-[61], see
parameter 13-01 Start Event Start
Event
MG33MI02 - Rev. 2013-11-20
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
Option: Function:
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available
on the graphical LCP.
[45] Left key [◄] is pressed. Only available on
the graphical LCP.
[46] Right key
[►] is pressed. Only available on
the graphical LCP.
▲
[47] Up key
[
the graphical LCP.
▼
[48] Down key
[
the graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
] is pressed. Only available on
] is pressed. Only available on
