Parameter Descriptions
15-10 Logging Source
Array [4]
Option:
[1657] Feedback [RPM]
[1660] Digital Input
3 3
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[1860] Digital Input 2
[3110] Bypass Status Word
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
15-11 Logging Interval
Array [4]
Range:
Size related
*
0.000 ]
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
154
Function:
Function:
[ 0.000 - Enter the interval in milliseconds
between each sampling of the
variables to be logged.
False
True
Running
In range
On reference
Torque limit
Current Limit
Out of current range
Below I low
Above I high
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reversing
Warning
®
VLT AutomationDrive FC 301/302 Programming Guide
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
[37]
[38]
[50]
[51]
[60]
[61]
15-13 Logging Mode
Option:
[0] Log always
[1] Log once on
trigger
Function:
15-14 Samples Before Trigger
Range:
50 [0 -
*
100 ]
MG33MI02 - Rev. 2013-11-20
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
Function:
Select [0] Log always for continuous logging.
Select [1] Log once on trigger to conditionally
start and stop logging using 15-12 Trigger
Event and 15-14 Samples Before Trigger.
Function:
Enter the percentage of all samples before a
trigger event which are to be retained in the
log. See also parameter 15-12 Trigger Event and
parameter 15-13 Logging Mode.
Function:
