Parameter Descriptions
8-17 Configurable Alarm and Warningword
The Configurable Alarm and Warning Word has 16 bits (0-15).
Each of those bits can be configured to any of the following
options.
Option:
[61] Feedback error warning
[62] Frequency max warning
[64] Voltage limit warning
[65] Controlboard overtemp warning
[66] Heatsink temp low warning
[68] Safe stop warning
[73] Safe stop autorestart warning
[76] Power unit setup warning
[77] Reduced powermode warning
[78] Tracking error warning
[89] Mech brake sliding warning
[163] ATEX ETR cur limit warning
[165] ATEX ETR freq limit warning
[10002] Live zero error alarm
[10004] Mains phase loss alarm
[10007] DC overvoltage alarm
[10008] DC undervoltage alarm
[10009] Inverter overload alarm
[10010] ETR overtemperature alarm
[10011] Thermistor overtemp alarm
[10012] Torque limit alarm
[10013] Overcurrent alarm
[10014] Earth fault alarm
[10016] Short circuit alarm
[10017] CTW timeout alarm
[10022] Hoist brake alarm
[10026] Brake powerlimit alarm
[10027] Brakechopper shortcircuit alarm
[10028] Brake check alarm
[10029] Heatsink temp alarm
[10030] Phase U missing alarm
[10031] Phase V missing alarm
[10032] Phase W missing alarm
[10033] Inrush fault alarm
[10034] Fieldbus com faul alarm
[10036] Mains failure alarm
[10037] Phase imbalance alarm
[10038] Internal fault
[10039] Heatsink sensor alarm
[10045] Earth fault 2 alarm
[10046] Powercard supply alarm
[10047] 24V supply low alarm
[10048] 1.8V supply low alarm
[10049] Speed limit alarm
[10060] Ext interlock alarm
[10061] Feedback error alarm
[10063] Mech brake low alarm
[10065] Controlboard overtemp alarm
[10067] Option config changed alarm
®
VLT AutomationDrive FC 301/302 Programming Guide
8-17 Configurable Alarm and Warningword
The Configurable Alarm and Warning Word has 16 bits (0-15).
Each of those bits can be configured to any of the following
options.
Function: Option:
[10068]
[10069]
[10073]
[10074]
[10075]
[10078]
[10079]
[10081]
[10082]
[10084]
[10090]
[10091]
[10164]
[10166]
8-19 Product Code
Range:
Size
related
*
3.10.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0] FC
*
[1] FC MC
[2] Modbus RTU
8-31 Address
Range:
Size related
8-32 FC Port Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
MG33MI02 - Rev. 2013-11-20
Safe stop alarm
Powercard temp alarm
Safestop auto restart alarm
PTC thermistor alarm
Illegal profile alarm
Tracking error alarm
Illegal PS config alarm
CSIV corrupt alarm
CSIV param error alarm
No safety option alarm
Feedback monitor alarm
AI54 settings alarm
ATEX ETR current lim alarm
ATEX ETR freq limit alarm
Function:
[0 - Select [0] to readout the actual
2147483647 ] fieldbus product code according
to the mounted fieldbus option.
Select [1] to readout the actual
Vendor ID.
Function:
Select the protocol to be used. Changing
protocol is not effective until after powering
off the frequency converter.
Function:
[ 1 - 255 ] Enter the address for the FC (standard)
*
port.
Valid range: 1-126.
Function:
Baud rate selection for the FC (standard) port.
Function:
