Danfoss VLT AutomationDrive FC 302 Programming Manual page 86

Parameter Descriptions
5-10 Terminal 18 Digital Input
Option: Function:
[8] Start Functions are described under parameter group 5-1*
*
Digital Inputs
5-11 Terminal 19 Digital Input
3 3
Option:
[10] Reversing Functions are described under parameter group
*
5-12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described under parameter
*
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for FC 302 only.
[14] Jog Functions are described under parameter group 5-1*
*
Digital Inputs
5-14 Terminal 32 Digital Input
Option:
No operation Functions are described under 5-1* Digital Inputs
5-15 Terminal 33 Digital Input
Option:
[0] No operation Functions are described under 5-1* Digital
*
5-16 Terminal X30/2 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-17 Terminal X30/3 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-18 Terminal X30/4 Digital Input
Option:
[0] No operation This parameter is active when option module
*
84
VLT
Function:
5-1* Digital Inputs
Function:
group 5-1* Digital Inputs
Function:
Select the function from the available digital
input range.
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
Inputs
Function:
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs
Function:
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs
Function:
MCB 101 is installed in the frequency
®
AutomationDrive FC 301/302 Programming Guide
5-18 Terminal X30/4 Digital Input
Option:
5-19 Terminal 37 Safe Stop
Option:
[1] Safe Stop
Alarm
[3] Safe Stop
Warning
[4] PTC 1 Alarm
[5] PTC 1
Warning
[6] PTC 1 &
Relay A
[7] PTC 1 &
Relay W
[8] PTC 1 &
Relay A/W
[9] PTC 1 &
Relay W/A
MG33MI02 - Rev. 2013-11-20
Function:
converter. Functions are described under
5-1* Digital Inputs
Function:
Coasts frequency converter when safe stop is
activated. Manual reset from LCP, digital input
or fieldbus.
Coasts frequency converter when safe stop is
activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset.
Coasts frequency converter when Safe Torque
Off is activated. Manual reset from LCP, digital
input or fieldbus.
Coasts frequency converter when Safe Torque
Off is activated (T-37 off). When Safe Torque
Off circuit is reestablished, the frequency
converter continues without manual reset,
unless a Digital Input set to[80] PTC Card 1 is
still enabled.
This choice is used when the PTC option is
gated together with a Stop button through a
Safety relay to T-37. Coasts frequency
converter when safe stop is activated. Manual
reset from LCP, digital input or fieldbus.
This option is used when the PTC option is
gated together with a Stop button through a
Safety relay to T-37. Coasts frequency
converter when Safe Torque Off is activated
(T-37 off). When safe stop circuit is reestab-
lished, the frequency converter continuea
without manual reset, unless a Digital Input
set to [80] PTC Card 1 is (still) enabled.
This option makes it possible to use a
combination of Alarm and Warning.
This option makes it possible to use a
combination of Alarm and Warning.
