Danfoss VLT AutomationDrive FC 302 Programming Manual page 166

Parameter Descriptions
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
3 3
16-87 Bus Readout Alarm/Warning
Range:
0 [0 - 65535 ] Alarm and Warning numbers in hex as
*
16-89 Configurable Alarm/Warning Word
Range:
0 [0 - 4294967295 ] This Alarm/Warning word is configured in
*
3.17.6 16-9* Diagnosis Read-Outs
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, i.e. as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
164
VLT
Function:
View the two-byte status word (STW) sent to
the Bus-Master. Interpretation of the status
word depends on the fieldbus option installed
and the control word profile selected in
8-10 Control Profile.
Function:
displayed in the Alarm log. The High byte
contains the Alarm, the Low byte the Warning.
The Alarm number is the first one that
occurred after the last reset.
Function:
parameter parameter 8-17 Configurable
Alarm and Warningword to match the
actual requirements.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
communication port in hex code.
®
AutomationDrive FC 301/302 Programming Guide
16-94 Ext. Status Word
Range:
0 [0 - 4294967295 ] Returns the extended warning word sent
*
MG33MI02 - Rev. 2013-11-20
Function:
via the serial communication port in hex
code.
