Danfoss VLT AutomationDrive FC 302 Programming Manual page 193

Parameter Lists
4.1.9 5-** Digital In/Out
Par. No. # Parameter description
5-0* Digital I/O mode
5-00 Digital I/O Mode
5-01 Terminal 27 Mode
5-02 Terminal 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
5-16 Terminal X30/2 Digital Input
5-17 Terminal X30/3 Digital Input
5-18 Terminal X30/4 Digital Input
5-19 Terminal 37 Safe Stop
5-20 Terminal X46/1 Digital Input
5-21 Terminal X46/3 Digital Input
5-22 Terminal X46/5 Digital Input
5-23 Terminal X46/7 Digital Input
5-24 Terminal X46/9 Digital Input
5-25 Terminal X46/11 Digital Input
5-26 Terminal X46/13 Digital Input
5-3* Digital Outputs
5-30 Terminal 27 Digital Output
5-31 Terminal 29 Digital Output
5-32 Term X30/6 Digi Out (MCB 101)
5-33 Term X30/7 Digi Out (MCB 101)
5-4* Relays
5-40 Function Relay
5-41 On Delay, Relay
5-42 Off Delay, Relay
5-5* Pulse Input
5-50 Term. 29 Low Frequency
5-51 Term. 29 High Frequency
5-52 Term. 29 Low Ref./Feedb. Value
5-53 Term. 29 High Ref./Feedb. Value
5-54 Pulse Filter Time Constant #29
5-55 Term. 33 Low Frequency
5-56 Term. 33 High Frequency
5-57 Term. 33 Low Ref./Feedb. Value
5-58 Term. 33 High Ref./Feedb. Value
5-59 Pulse Filter Time Constant #33
5-6* Pulse Output
Terminal 27 Pulse Output
5-60 Variable
5-62 Pulse Output Max Freq #27
®
VLT AutomationDrive FC 301/302 Programming Guide
Default value 4-set-up
[0] PNP All set-ups
[0] Input All set-ups
[0] Input All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0.01 s All set-ups
0.01 s All set-ups
100 Hz All set-ups
100 Hz All set-ups
0 ReferenceFeed-
backUnit All set-ups
ExpressionLimit All set-ups
100 ms All set-ups
100 Hz All set-ups
100 Hz All set-ups
0 ReferenceFeed-
backUnit All set-ups
ExpressionLimit All set-ups
100 ms All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
MG33MI02 - Rev. 2013-11-20
FC 302 Change Conver-
only during sion index
operation
FALSE -
TRUE -
x TRUE -
TRUE -
TRUE -
TRUE -
x TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
x TRUE -
TRUE -
TRUE -
TRUE -
TRUE -2
TRUE -2
x TRUE 0
x TRUE 0
x TRUE -3
x TRUE -3
x FALSE -3
TRUE 0
TRUE 0
TRUE -3
TRUE -3
FALSE -3
TRUE -
TRUE 0
Type
Uint8
Uint8
4 4
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint32
Uint32
Int32
Int32
Uint16
Uint32
Uint32
Int32
Int32
Uint16
Uint8
Uint32
191
