Parameter Descriptions
NOTICE
To change the set-up after a time-out, the following
configuration is required:
Set parameter 0-10 Active Set-up to [9] Multi set-up and
select the relevant link in parameter 0-12 This Set-up
Linked to.
8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control
word following a time-out. This parameter is
active only when 8-04 Control Timeout Function
is set to [7] Set-up 1, [8] Set-up 2, [9]Set-up 3 or
[10] Set-up 4.
[0] Hold set- Retains the set-up selected in 8-04 Control
up Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-up.
[1] Resume Resumes the set-up active before the time-out.
set-up
8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option: Function:
[0] Do not reset Retains the set-up specified in
*
parameter 8-04 Control Word Timeout Function,
following a control word time-out.
[1] Do reset Returns the frequency converter to the
original set-up following a control word time-
out. The frequency converter performs the
reset and then immediately reverts to the [0]
Do not reset setting
8-07 Diagnosis Trigger
This parameter has no function for DeviceNet.
Option: Function:
[0] Disable
*
[1] Trigger on alarms
[2] Trigger alarm/warn. This parameter has no function for
DeviceNet.
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered, if the function is required. A
power-cycle is required for changes to take effect.
Option: Function:
[0] Motor Data Select [0] for normal bus readouts.
Std-Filt.
[1] Motor Data Select [1] for filtered bus readouts of
LP-Filter the following parameters:
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
®
VLT AutomationDrive FC 301/302 Programming Guide
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered, if the function is required. A
power-cycle is required for changes to take effect.
Option:
3.10.2 8-1* Ctrl. Word Settings
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A are visible in the LCP display.
For guidelines in selection of [0] FC profile and [1] PROFIdrive
profile, refer to the Serial communication via RS-485 Interface
section in the Design Guide.
For additional guidelines in the selection of [1] PROFIdrive profile,
refer to the Operating Instructions for the installed fieldbus.
Option:
[0]
*
[1]
[5]
[7]
[8]
8-13 Configurable Status Word STW
The status word has 16 bits (0-15). Bits 5 and 12-15 are config-
urable. Each of these bits can be configured to any of the
following options.
Option:
[0]
[1]
[2]
[3]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
MG33MI02 - Rev. 2013-11-20
Function:
16-14 Motor current
Parameter 16-16 Torque [Nm]
Parameter 16-17 Speed [RPM]
Parameter 16-22 Torque [%]
Parameter 16-25 Torque [Nm] High
FC profile
PROFIdrive profile
ODVA
CANopen DSP 402
MCO
Function:
No function The input is always low.
Profile Default Depended on the profile
set in 8-10 Control Profile.
Alarm 68 Only The input goes high
whenever Alarm 68 is
active and goes low
whenever no alarm 68 is
actived
Trip excl Alarm 68
T18 DI status
T19 DI status
T27 DI status
T29 DI status
T32 DI status
T33 DI status
T37 DI status The input goes high
whenever T37 has 0 V and
goes low whenever T37
has 24 V
3
Function:
115
3
