Parameter Lists
Par. No. # Parameter description
32-90 Debug Source
4.1.24 33-** MCO Adv. Settings
Par. No. # Parameter description
33-0* Home Motion
33-00 Force HOME
Zero Point Offset from Home
33-01 Pos.
33-02 Ramp for Home Motion
33-03 Velocity of Home Motion
Behaviour during
33-04 HomeMotion
33-1* Synchronization
33-10 Sync Factor Master
33-11 Sync Factor Slave
Position Offset for Synchroni-
33-12 zation
Accuracy Window for Position
33-13 Sync.
33-14 Relative Slave Velocity Limit
33-15 Marker Number for Master
33-16 Marker Number for Slave
33-17 Master Marker Distance
33-18 Slave Marker Distance
33-19 Master Marker Type
33-20 Slave Marker Type
Master Marker Tolerance
33-21 Window
Slave Marker Tolerance
33-22 Window
Start Behaviour for Marker
33-23 Sync
33-24 Marker Number for Fault
33-25 Marker Number for Ready
33-26 Velocity Filter
33-27 Offset Filter Time
33-28 Marker Filter Configuration
33-29 Filter Time for Marker Filter
33-30 Maximum Marker Correction
33-31 Synchronisation Type
Feed Forward Velocity
33-32 Adaptation
33-33 Velocity Filter Window
33-34 Slave Marker filter time
33-4* Limit Handling
33-40 Behaviour atEnd Limit Switch
33-41 Negative Software End Limit
33-42 Positive Software End Limit
®
