Introduction

1.6 Electrical Wiring

91 (L1)
3 Phase
92 (L2)
power
93 (L3)
input
95
88 (-)
DC bus
89 (+)
50 (+10 V OUT)
+10Vdc
0/-10Vdc -
53 (A IN)
+10Vdc
0/4-20 mA
0/-10Vdc -
54 (A IN)
+10Vdc
0/4-20 mA
55 (COM A IN)
12 (+24V OUT)
13 (+24V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27
*
29
32 (D IN)
33 (D IN)
*
37 (D IN)
Illustration 1.2 Basic Wiring Schematic Drawing
A=Analog, D=Digital
Terminal 37 is used for Safe Torque Off. For Safe Torque Off installation instructions, refer to the Operating Instructions.
* Terminal 37 is not included in FC 301 (except enclosure type A1). Relay 2 and terminal 29 have no function in FC 301.
** Do not connect cable screen.
Very long control cables and analog signals may in rare cases and depending on installation result in 50/60 Hz earth loops
due to noise from mains supply cables.
If this occurs, it may be necessary to break the screen or insert a 100 nF capacitor between screen and chassis.
The digital and analog inputs and outputs must be connected separately to the common inputs (terminal 20, 55, 39) of the
frequency converter to avoid ground currents from both groups to affect other groups. For example, switching on the
digital input may disturb the analog input signal.
®
VLT AutomationDrive FC 301/302 Programming Guide
PE
Switch Mode
Power Supply
10Vdc
15mA
+ -
S201
ON=0/4-20mA
S202
OFF=0/-10Vdc -
+10Vdc
P 5-00
24V (NPN)
0V (PNP)
24V (NPN)
0V (PNP)
24V (NPN)
(D IN/OUT)
0V (PNP)
24V
0V
24V (NPN)
(D IN/OUT)
0V (PNP)
24V
0V
24V (NPN)
0V (PNP)
24V (NPN)
0V (PNP)
MG33MI02 - Rev. 2013-11-20
(U) 96
(V) 97
(W) 98
(PE) 99
24Vdc
(R+) 82
130/200mA
+ -
(R-) 81
relay1
* relay2
(COM A OUT) 39
(A OUT) 42
S801
ON=Terminated
OFF=Open
5V
S801
RS-485
(N RS-485) 69
Interface
(P RS-485) 68
(COM RS-485) 61
Motor
Brake
resistor
03
240Vac, 2A
02
01
06
240Vac, 2A
05
400Vac, 2A
04
Analog Output
0/4-20 mA
0V
RS-485
**
: Chassis
: Earth
1 1
9
