Parameter Descriptions
8-32 FC Port Baud Rate
Option:
[6] 76800 Baud
[7] 115200 Baud
3 3
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-34 Estimated cycle time
Range:
0 ms [0 -
*
1000000 ms]
8-35 Minimum Response Delay
Range:
10 ms [ 1 - 10000
*
ms]
8-36 Max Response Delay
Range:
Size
related 10001 ms]
*
8-37 Max Inter-Char Delay
Range:
Size
related 35.00 ms]
*
3.10.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option:
[1] Standard telegram 1 Enables use of freely configurable
*
118
Function:
Function:
In noisy environments, the interface may
be blocked due to overload or bad frames.
This parameter specifies the time between
2 consecutive frames on the network. If the
interface does not detect valid frames in
that time, it flushes the receive buffer.
Function:
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
Function:
[ 11 - Specify the maximum permissible
delay time between transmitting a
request and receiving a response. If a
response from the frequency converter
is exceeding the time setting, then it is
discarded.
Function:
[ 0.00 - Specify the maximum permissible time
interval between receipt of 2 bytes.
This parameter activates time-out if
transmission is interrupted.
This parameter is active only when
8-30 Protocol is set to [1] FC MC
protocol.
Function:
telegrams or standard telegrams for
the FC port.
®
VLT AutomationDrive FC 301/302 Programming Guide
8-40 Telegram Selection
Option:
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
Function:
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
8-41 Parameters for Signals
Option:
[0]
*
[15]
[302]
[303]
[312]
[341]
[342]
[351]
[352]
[380]
[381]
[411]
[412]
[413]
[414]
[416]
[417]
[553]
[558]
[590]
[593]
[595]
[597]
[615]
[625]
[653]
[663]
[673]
MG33MI02 - Rev. 2013-11-20
Function:
Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
None
Readout: actual setup
Minimum Reference
Maximum Reference
Catch up/slow Down Value
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Ramp Time
Motor Speed Low Limit [RPM]
Motor Speed Low Limit [Hz]
Motor Speed High Limit [RPM]
Motor Speed High Limit [Hz]
Torque Limit Motor Mode
Torque Limit Generator Mode
Term. 29 High Ref./Feedb. Value
Term. 33 High Ref./Feedb. Value
Digital & Relay Bus Control
Pulse Out #27 Bus Control
Pulse Out #29 Bus Control
Pulse Out #X30/6 Bus Control
Terminal 53 High Ref./Feedb. Value
Terminal 54 High Ref./Feedb. Value
Term 42 Output Bus Ctrl
Terminal X30/8 Bus Control
Terminal X45/1 Bus Control
Function:
This parameter
contains a list of
signals available for
selection in
parameter 8-42 PCD
Write Configuration
and
parameter 8-43 PCD
Read Configuration.
