Parameter Descriptions
6-60 Terminal X30/8 Output
Option:
3 3
[102] Feedback
[103] Motor
Current
[104] Torque rel
to limit
[105] Torq relate
to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out
Freq
[113] PID
Clamped
Output
[119] Torque %
lim
[130] Output freq.
4-20mA
[131] Reference
4-20mA
[132] Feedback
4-20mA
[133] Motor cur.
4-20mA
104
®
VLT
Function:
Parameter 3-00 Reference Range [-Max - Max]
-100% = 0 mA; 0% = 10 mA; +100% = 20
mA
Value is taken from parameter 16-37 Inv.
Max. Current. Inverter max. current (160%
current) is equal to 20 mA.
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22
A Read-out 11.46 mA.
mA x 22 A
20
= 11.46 mA
38.4 A
In case the norm motor current is equal to
20 mA, the output setting of
parameter 6-62 Terminal X30/8 Max. Scale is:
IVLT Max x 100
38.4 x 100
= = 175%
IMotor Norm 22
The torque setting is related to setting in
parameter 4-16 Torque Limit Motor Mode.
The torque is related to the motor torque
setting.
Taken from parameter 1-20 Motor Power
[kW].
Taken from parameter 3-03 Maximum
Reference. 20 mA = value in
parameter 3-03 Maximum Reference
Torque reference related to 160% torque.
In relation to parameter 4-19 Max Output
Frequency.
0 Hz = 4 mA, 100 Hz = 20 mA
Parameter 3-00 Reference Range [Min-Max]
0% = 4 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max-Max]
-100% = 4 mA; 0% = 12 mA; +100% = 20
mA
Value is taken from parameter 16-37 Inv.
Max. Current. Inverter max. current (160%
current) is equal to 20 mA.
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22
A Read-out 11.46 mA.
16 mA x 22 A
mA
= 9.17
38.4 A
AutomationDrive FC 301/302 Programming Guide
6-60 Terminal X30/8 Output
Option:
[134] Torq.% lim
4-20 mA
[135] Torq.% nom
4-20mA
[136] Power
4-20mA
[137] Speed
4-20mA
[138] Torque
4-20mA
[139] Bus ctrl.
0-20 mA
[140] Bus ctrl.
4-20 mA
[141] Bus ctrl
0-20mA t.o.
[142] Bus ctrl
4-20mA t.o.
[149] Torque %
lim 4-20mA
[150] Max Out Fr
4-20mA
6-61 Terminal X30/8 Min. Scale
Range:
0 % [0 -
*
200 %]
MG33MI02 - Rev. 2013-11-20
Function:
In case the norm motor current is equal to
20 mA, the output setting of
parameter 6-62 Terminal X30/8 Max. Scale is:
IVLT Max x 100
38.4 x 100
= = 175%
IMotor Norm 22
The torque setting is related to setting in
parameter 4-16 Torque Limit Motor Mode.
The torque setting is related to the motor
torque setting.
Taken from parameter 1-20 Motor Power [kW]
Taken from parameter 3-03 Maximum
Reference. 20 mA = Value in
parameter 3-03 Maximum Reference.
Torque reference related to 160% torque.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency
converter.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency
converter.
Parameter 4-54 Warning Reference Low
defines the behaviour of the analog output
in case of bus time-out.
Parameter 4-54 Warning Reference Low
defines the behaviour of the analog output
in case of bus time-out.
Torque% Lim 4-20 mA: Torque reference.
parameter 3-00 Reference Range [Min-Max]
0% = 4 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max]
-100% = 4 mA; 0% = 12 mA; +100% = 20
mA
In relation to parameter 4-19 Max Output
Frequency.
Function:
Scales the minimum output of the selected
analog signal on terminal X30/8. Scale the
minimum value as a percentage of the maximum
signal value, i.e. 0 mA (or 0 Hz) is desired at 25%
of the maximum output value and 25% is
programmed. The value can never be higher than
the corresponding setting in 6-62 Terminal X30/8
Max. Scale if value is below 100%.
This parameter is active when option module
MCB 101 is mounted in the frequency converter.
