Parameter Descriptions
13-51 SL Controller Event
Array [20]
Option:
[110] Relay 9
3 3
13-52 SL Controller Action
Array [20]
Option:
[0] DISABLED
[1] No action
[2] Select set-up 1 Changes the active set-up
[3] Select set-up 2 Changes the active set-up
[4] Select set-up 3 Changes the active set-up
[5] Select set-up 4 Changes the active set-up
[10] Select preset
ref 0
[11] Select preset
ref 1
[12] Select preset
ref 2
[13] Select preset
ref 3
140
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
X34/MCB 105
Function:
Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions are
available for selection:
[0] *DISABLED
(parameter 0-10 Active Set-up) to '1'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
parameter 0-10 Active Set-up) to '2'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(parameter 0-10 Active Set-up) to '3'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(parameter 0-10 Active Set-up) to '4'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
Selects preset reference 0.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 1.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 2.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 3.
13-52 SL Controller Action
Array [20]
Option:
[14] Select preset
ref 4
[15] Select preset
ref 5
[16] Select preset
ref 6
[17] Select preset
ref 7
[18] Select ramp 1
[19] Select ramp 2
[20] Select ramp 3
[21] Select ramp 4
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
MG33MI02 - Rev. 2013-11-20
Function:
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 4.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 5.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 6.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 7.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects ramp 1.
Selects ramp 2.
Selects ramp 3.
Selects ramp 4.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a quick stop command to the
frequency converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
Freezes the output frequency of the
frequency converter.
Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
