Parameter Descriptions
13-43 Logic Rule Operator 2
Array [6]
Option: Function:
Select the second logical operator to be used
on the boolean input calculated in
13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1, and
13-42 Logic Rule Boolean 2, and the boolean
input coming from 13-42 Logic Rule Boolean
2.
[13-44] signifies the boolean input of
13-44 Logic Rule Boolean 3.
[13-40/13-42] signifies the boolean input
calculated in 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1, and
13-42 Logic Rule Boolean 2. [0] Disabled
(factory setting). select this option to ignore
13-44 Logic Rule Boolean 3.
[0] DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Option:
[0] False Select the third boolean (TRUE or
FALSE) input for the selected logic
rule. See parameter 13-01 Start
Event ([0] - [61]) and
parameter 13-02 Stop Event ([70] -
[75]) for further description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
MG33MI02 - Rev. 2013-11-20
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available
on the graphical LCP.
[45] Left key [◄] is pressed. Only available on
the graphical LCP.
[46] Right key
[►] is pressed. Only available on
the graphical LCP.
▲
[47] Up key
[
the graphical LCP.
▼
[48] Down key
[
the graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
] is pressed. Only available on
] is pressed. Only available on
