Parameter Descriptions

3.17 Parameters: 16-** Data Read-outs

16-00 Control Word
Range: Function:
0 [0 - 65535 ] View the Control word sent from the
*
frequency converter via the serial communi-
cation port in hex code.
16-01 Reference [Unit]
Range:
0 ReferenceFeed- [-999999 - 999999
backUnit ReferenceFeed-
*
backUnit]
16-02 Reference [%]
Range: Function:
0 % [-200 - 200 View the total reference. The total reference
*
%] is the sum of digital, analog, preset, bus,
and freeze references, plus catch-up and
slow-down.
16-03 Status Word
Range: Function:
0 [0 - 65535 ] View the status word sent from the frequency
*
converter via the serial communication port in
hex code.
16-05 Main Actual Value [%]
Range: Function:
0 % [-100 - 100 %] View the 2-byte word sent with the status
*
word to the Bus Master reporting the
Main Actual Value.
16-09 Custom Readout
Range:
0 CustomRea- [0 - 0 Custom-
doutUnit ReadoutUnit]
*
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
View the present
reference value applied
on impulse or analog
basis in the unit
resulting from the
configuration selected in
1-00 Configuration Mode
(Hz, Nm, or RPM).
Function:
View the value of custom
readout from
parameter 0-30 Unit for User-
defined Readout to
parameter 0-32 Custom Readout
Max Value
MG33MI02 - Rev. 2013-11-20
3.17.1 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW [0 - Displays motor power in kW. The value shown
*
10000 is calculated based on the actual motor
kW] voltage and motor current. The value is
filtered, and therefore approx. 30 ms may pass
from when an input value changes to when
the data readout values change. The
resolution of readout value on fieldbus is in
10 W steps.
16-11 Power [hp]
Range: Function:
0 hp [0 - View the motor power in hp. The value
*
10000 hp] shown is calculated based on the actual
motor voltage and motor current. The value
is filtered, and therefore approximately 30 ms
may pass from when an input value changes
to when the data readout values change.
16-12 Motor Voltage
Range: Function:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
used for controlling the motor.
16-13 Frequency
Range: Function:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
resonance dampening.
16-14 Motor current
Range: Function:
0 A [0 - 10000 View the motor current measured as a mean
*
A] value, I . The value is filtered, and thus
RMS
approximately 30 ms may pass from when an
input value changes to when the data
readout values change.
16-15 Frequency [%]
Range: Function:
0 % [-100 - View a 2-byte word reporting the actual motor
*
100 %] frequency (without resonance dampening) as a
percentage (scale 0000-4000 Hex) of
parameter 4-19 Max Output Frequency. Set
9-16 PCD Read Configuration index 1 to send it
with the status word instead of the MAV.
16-16 Torque [Nm]
Range: Function:
0 [-3000 View the torque value with sign, applied to the
Nm - 3000 motor shaft. Linearity is not exact between
*
Nm] 160% motor current and torque in relation to
