Parameter Descriptions
0-13 Readout: Linked Set-ups
Array [5]
Range:
0 [0 -
*
255 ]
3 3
0-14 Readout: Edit Set-ups / Channel
Range:
0 [-2147483648 -
*
2147483647 ]
0-15 Readout: actual setup
Range:
0 [0 - 255 ] Makes it possible to read out the active set-up,
*
3.2.3 0-2* LCP Display
Define the variables displayed in the Graphical Local
Control Panel.
NOTICE
Refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write
display texts.
28
VLT
Function:
View a list of all the set-ups linked by means of
0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which
set-ups are linked to that parameter set-up.
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 3.2 Example: Set-up 1 and Set-up 2 are
linked
Function:
View the setting of parameter 0-11 Edit Set-
up for each of the 4 different
communication channels. When the
number is displayed as a hex number, as it
is in the LCP, each number represents one
channel.
Numbers 1-4 represent a set-up number; 'F'
means factory setting; and 'A' means active
set-up. The channels are, from right to left:
LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in
parameter 0-11 Edit Set-up, the LCP selected
Set-up 1 and all others used the active set-
up.
Function:
also when multi set-up is selected in
parameter 0-10 Active Set-up.
®
AutomationDrive FC 301/302 Programming Guide
0-20 Display Line 1.1 Small
Option:
[0] None
[9] Performance
Monitor
[15] Readout: actual
setup
[37] Display Text 1
[38] Display Text 2
[39] Display Text 3
[748] PCD Feed Forward
[953] Profibus Warning
Word
[1005] Readout Transmit
Error Counter
[1006] Readout Receive
Error Counter
[1007] Readout Bus Off
Counter
[1013] Warning Parameter
[1230] Warning Parameter
[1472] Legacy Alarm Word
[1473] Legacy Warning
Word
[1474] Leg. Ext. Status
Word
[1501] Running Hours
[1502] kWh Counter
[1580] Fan Running Hours
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value
[%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
MG33MI02 - Rev. 2013-11-20
Function:
Select a variable for display in line
1, left position.
No display value selected.
Present control word
Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in selected
unit.
Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in percent.
Present status word.
Actual value as a percentage.
Actual power consumed by the
motor in kW.
Actual power consumed by the
motor in hp.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz
