Parameter Descriptions
14-56 Capacitance Output Filter
Compensation function of the LC-filter requires the per phase
equivalent star-connected capacitance of the filter (3 times the
capacity between 2 phases when capacitance is 'Delta'
connection).
Range: Function:
Size related [0.1 - 6500 Set the capacitance of the output
*
uF] filter. The value can be found on the
filter label.
NOTICE
This is required for correct
compensation in Flux mode
(parameter 1-01 Motor Control
Principle)
14-57 Inductance Output Filter
Range: Function:
Size [0.001 - Set the inductance of the output filter.
related 65 mH] The value can be found on the filter
*
label.
NOTICE
This is required for correct
compensation in Flux mode
(parameter 1-01 Motor Control
Principle)
14-59 Actual Number of Inverter Units
Range: Function:
Size related [ 1 - 1 ] Set the actual number of power units.
*
3.15.8 14-7* Compatibility
The parameters in this group are for setting of compati-
bility for VLT 3000, VLT 5000 to FC 300.
14-72 VLT Alarm Word
Option: Function:
[0] 0 - 4294967295 Read out the alarm word corresponding to
VLT 5000.
14-73 VLT Warning Word
Option: Function:
[0] 0 - 4294967295 Read out the warning word corresponding
to VLT 5000.
14-74 Leg. Ext. Status Word
Range: Function:
0 [0 - 4294967295 ] Read out the ext. status word
*
corresponding to VLT 5000
®
VLT AutomationDrive FC 301/302 Programming Guide
3.15.9 14-8* Options
14-80 Option Supplied by External 24VDC
Option:
[0] No
[1] Yes Select [1] Yes if an external 24 V DC supply is used to
*
NOTICE
This parameter is only changing function by performing
a power cycle.
14-88 Option Data Storage
Range:
0 [0 - 65535 ] This parameter stores options data over a
*
14-89 Option Detection
Selects the behaviour of the frequency converter when a change
in the option configuration is detected.
Option:
[0] Protect Option
*
Config.
[1] Enable Option
Change
14-90 Fault Level
Use this parameter to customise fault levels.
Option:
[0] Off
[1] Warning
[2] Trip
[3] Trip Lock
[4] Trip w.
delayed reset
MG33MI02 - Rev. 2013-11-20
Function:
Select [0] No to use the frequency converter's 24 V DC
supply.
power the option. Inputs/Outputs are galvanically
isolated from the frequency converter when operated
from an external supply.
Function:
power cycle.
Function:
Freezes the current settings and
prevents unwanted changes when
missing or defective options are
detected.
Changes frequency converter settings
and is used when modifying the
system configuration. This parameter
setting returns to [0] Protect Option
Config. after an Option Change.
Function:
Use [0] Off with caution as it ignores all
Warnings & Alarms for the selected source.
Changing a fault level from default option
[3] Trip Lock to [2] Trip leads to the
automatic reset of the alarm. For alarms
involving over-current, the frequency
converter has a hardware protection that
issues a 3 minute recovery after 2
consecutive over-current incidents, this
hardware protection cannot be overruled.
