4.1.26 35-** Sensor Input Option
Par. No. #
Parameter description
35-0* Temp. Input Mode
35-00
Term. X48/4 temp. unit
35-01
Term. X48/4 input type
4
4
35-02
Term. X48/7 temp. unit
35-03
Term. X48/7 input type
35-04
Term. X48/10 temp. unit
35-05
Term. X48/10 input type
Temperature sensor alarm
35-06
function
35-1* Temp. Input X48/4
Term. X48/4 filter time
35-14
constant
35-15
Term. X48/4 temp. monitor
35-16
Term. X48/4 low temp. limit
35-17
Term. X48/4 high temp. limit
35-2* Temp. Input X48/7
Term. X48/7 filter time
35-24
constant
35-25
Term. X48/7 temp. monitor
35-26
Term. X48/7 low temp. limit
35-27
Term. X48/7 high temp. limit
35-3* Temp. Input X48/10
Term. X48/10 filter time
35-34
constant
35-35
Term. X48/10 temp. monitor
35-36
Term. X48/10 low temp. limit
35-37
Term. X48/10 high temp. limit
35-4* Analog Input X48/2
35-42
Term. X48/2 low current
35-43
Term. X48/2 high current
Term. X48/2 low ref./feedb.
35-44
value
Term. X48/2 high ref./feedb.
35-45
value
Term. X48/2 filter time
35-46
constant
210
®
VLT
AutomationDrive FC 301/302 Programming Guide
Default value
4-set-up
[60] °C
All set-ups
[0] Not Connected
All set-ups
[60] °C
All set-ups
[0] Not Connected
All set-ups
[60] °C
All set-ups
[0] Not Connected
All set-ups
[5] Stop and trip
All set-ups
0.001 s
All set-ups
[0] Disabled
All set-ups
App.Dependent
All set-ups
App.Dependent
All set-ups
0.001 s
All set-ups
[0] Disabled
All set-ups
App.Dependent
All set-ups
App.Dependent
All set-ups
0.001 s
All set-ups
[0] Disabled
All set-ups
App.Dependent
All set-ups
App.Dependent
All set-ups
4.00 mA
All set-ups
20.00 mA
All set-ups
0.000 N/A
All set-ups
100.000 N/A
All set-ups
0.001 s
All set-ups
MG33MI02 - Rev. 2013-11-20
FC 302
Change
Conver-
only
during
sion index
operation
TRUE
-
TRUE
-
TRUE
-
TRUE
-
TRUE
-
TRUE
-
TRUE
-
TRUE
-3
TRUE
-
TRUE
0
TRUE
0
TRUE
-3
TRUE
-
TRUE
0
TRUE
0
TRUE
-3
TRUE
-
TRUE
0
TRUE
0
TRUE
-5
TRUE
-5
TRUE
-3
TRUE
-3
TRUE
-3
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Int16
Int16
Uint16
Uint8
Int16
Int16
Uint16
Uint8
Int16
Int16
Int16
Int16
Int32
Int32
Uint16
