Parameter Descriptions
1-34 Rotor Leakage Reactance (X2)
Range: Function:
1.
2.
3.
See Illustration 3.6.
NOTICE
The parameter value is updated
after each torque calibration if
option [3] 1st start with store or
option [4] Every start with store is
selected in parameter
parameter 1-47 Torque Calibration.
NOTICE
This parameter is only relevant for
ASM.
1-35 Main Reactance (Xh)
Range: Function:
Size [ 1.0000 - Set the main reactance of the motor
related 10000.0000 using one of these methods:
*
Ohm]
1.
2.
3.
1-36 Iron Loss Resistance (Rfe)
Range: Function:
Size [ 0 - Enter the equivalent iron loss
related 10000.000 resistance (R
*
Ohm] for iron loss in the motor.
The R
performing an AMA.
The R
torque control applications. If R
®
VLT AutomationDrive FC 301/302 Programming Guide
Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
Enter the X value manually.
2
Obtain the value from the
motor supplier.
Use the X default setting. The
2
frequency converter establishes
the setting based on the motor
nameplate data.
Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
Enter the X value manually.
h
Obtain the value from the
motor supplier.
Use the X default setting.
h
The frequency converter
establishes the setting based
on the motor nameplate data.
) value to compensate
Fe
value cannot be found by
Fe
value is especially important in
Fe
is
Fe
MG33MI02 - Rev. 2013-11-20
1-36 Iron Loss Resistance (Rfe)
Range: Function:
unknown, leave parameter 1-36 Iron
Loss Resistance (Rfe) on default setting.
1-37 d-axis Inductance (Ld)
Range: Function:
Size [0.0 - Enter line to common direct axis
related 1000.0 inductance of the PM motor. Obtain the
*
mH] value from the permanent magnet motor
data sheet.
If only line-line data are available, divide
the line-line value by 2 to achieve the
line-common (starpoint) value. Alterna-
tively measure the value with an
inductancemeter, this also takes the
inductance of the cable into account.
Divide the measured value by 2 and enter
the result.
This parameter is only active when
parameter 1-10 Motor Construction has the
value [1] PM, non-salient SPM (Permanent
Magnet Motor).
For a selection with one decimal, use this
parameter. For a selection with three
decimals, use parameter 30-80 d-axis
Inductance (Ld).
FC 302 only.
NOTICE
The parameter value is updated
after each torque calibration if
option [3] 1st start with store or
option [4] Every start with store is
selected in parameter
parameter 1-47 Torque Calibration.
NOTICE
This parameter is only relevant for
ASM.
1-38 q-axis Inductance (Lq)
Range:
Size related [0.000 - 1000
*
mH]
1-39 Motor Poles
Range: Function:
Size related [2 - 128 ] Enter the number of motor poles.
*
Function:
Set the value of the q-axis
inductance. See the motor data
sheet.
