Parameter Descriptions
8-13 Configurable Status Word STW
The status word has 16 bits (0-15). Bits 5 and 12-15 are config-
urable. Each of these bits can be configured to any of the
following options.
Option:
3 3
[21] Thermal warning
[30] Brake fault (IGBT)
[40] Out of ref range
[41] Load throttle active
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL digital out A
[81] SL digital out B
[82] SL digital out C
[83] SL digital out D
[84] SL digital out E
[85] SL digital out F
[86] ATEX ETR cur. alarm
[87] ATEX ETR freq. alarm
[88] ATEX ETR cur. warning
[89] ATEX ETR freq. warning
[90] Safe Function active
[91] Safe Opt. Reset req.
8-14 Configurable Control Word CTW
Option:
[0] None
[1] Profile
*
default
[2] CTW Valid,
active low
[3] Safe
Option
Reset
[4] PID error
inverse
[5] PID reset I
part
116
VLT
Function:
Function:
Selection of control word bit 10, if it is active
low or active high.
When enabled, it inverts the resulting error
from the process PID controller. Available only
if parameter 1-00 Configuration Mode is set to
[6] Surface Winder, [7] Extended PID Speed OL or
[8] Extended PID Speed CL.
When enabled, resets the I-part of the Process
PID controller. Equivalent to
parameter 7-40 Process PID I-part Reset.
®
AutomationDrive FC 301/302 Programming Guide
8-14 Configurable Control Word CTW
Option:
[6] PID enable When enabled, enables the extended process
8-17 Configurable Alarm and Warningword
The Configurable Alarm and Warning Word has 16 bits (0-15).
Each of those bits can be configured to any of the following
options.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[17]
[19]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[34]
[36]
[40]
[41]
[45]
[47]
[58]
[59]
[60]
MG33MI02 - Rev. 2013-11-20
Function:
Available only if parameter 1-00 Configuration
Mode is set to [6] Surface Winder, [7] Extended
PID Speed OL or [8] Extended PID Speed CL.
PID controller. Equivalent to
parameter 7-50 Process PID Extended PID.
Available only if parameter 1-00 Configuration
Mode is set to [6] Surface Winder, [7] Extended
PID Speed OL or [8] Extended PID Speed CL.
Off
10 Volts low warning
Live zero warning
No motor warning
Mains phase loss warning
DC link voltage high warning
DC link voltage low warning
DC overvoltage warning
DC undervoltage warning
Inverter overloaded warning
Motor ETR overtemp warning
Motor thermistor overtemp warning
Torque limit warning
Over current warning
Earth fault warning
Controlword timeout warning
Discharge temp high warning
Hoist mech brake warning
Internal fans warning
External fans warning
Brake resistor short circuit warning
Brake powerlimit warning
Brake chopper short circuit warning
Brake check warning
Heatsink temperature warning
Motor phase U warning
Motor phase V warning
Motor phase W warning
Fieldbus communication warning
Mains failure warning
T27 overload warning
T29 overload warning
Earth fault 2 warning
24V supply low warning
AMA internal fault warning
Current limit warning
External interlock warning
