How to Programme
0RPM 0.00A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q4 Smart Setup
Q5 Changes Made
Illustration 2.13 Quick Menus
Select Q2 Quick Setup to go through a limited amount of
parameters to get the motor running almost optimally. The
default setting for the other parameters considers the
desired control functions and the configuration of signal
inputs/outputs (control terminals).
The parameter selection is effected with the navigation
keys. The parameters in Table 2.2 are accessible.
Parameter
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
Parameter 1-29 Automatic Motor
Adaptation (AMA)
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-41 Ramp 1 Ramp Up Time
Parameter 3-42 Ramp 1 Ramp Down
Time
Parameter 3-13 Reference Site
Table 2.2 Selection of Parameter
* If terminal 27 is set to [0] No function, no connection to +24 V on
terminal 27 is necessary.

2.1.7 Initial Commissioning

The easiest way of carrying out the initial commissioning is by pressing [Quick Menu] and following the quick set-up
procedure using LCP 102 (read Table 2.3 from left to right). The example applies to open loop applications.
Press
Quick
Menu
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
®
VLT AutomationDrive FC 301/302 Programming Guide
Select Changes made to get information about:
1(1)
Select Loggings to get information about the display line
read-outs. The information is shown as graphs.
Only display parameters selected in parameter 0-20 Display
Line 1.1 Small and 0-24 Display Line 3 Large can be viewed.
It is possible to store up to 120 samples in the memory for
later reference.
Setting
[kW]
[V]
[Hz]
[A]
[RPM]
[0] No function*
[1] Enable complete
AMA
[RPM]
[RPM]
[s]
[s]
Q2 Quick Menu
OK Set language
OK Set Motor nameplate power
MG33MI02 - Rev. 2013-11-20
•
the last 10 changes. Use the [
keys to scroll between the last 10 changed
parameters.
•
the changes made since default setting.
OK
▲ ▼ 2
] [ ] navigation
