Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
Logic Action [32]. Output A is high on
Smart Logic Action [38].
[81] SL digital output B See parameter 13-52 SL Controller
Action. Output B is low on Smart
Logic Action [33]. Output B is high on
Smart Logic Action [39].
[82] SL digital output C See parameter 13-52 SL Controller
Action. Output C is low on Smart
Logic Action [34]. Output C is high on
Smart Logic Action [40].
[83] SL digital output D See parameter 13-52 SL Controller
Action. Output D is low on Smart
Logic Action [35]. Output D is high on
Smart Logic Action [41].
[84] SL digital output E See parameter 13-52 SL Controller
Action. Output E is low on Smart Logic
Action [36]. Output E is high on Smart
Logic Action [42].
[85] SL digital output F See parameter 13-52 SL Controller
Action. Output F is low on Smart Logic
Action [37]. Output F is high on Smart
Logic Action [43].
[120] Local ref active Output is high when 3-13 Reference
Site = [2] Local or when 3-13 Reference
Site = [0] Linked to hand auto at the
same time as the LCP is in Hand On
mode.
®
VLT AutomationDrive FC 301/302 Programming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[121] Remote ref active
[122] No alarm
[123] Start command
activ
[124] Running reverse
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
MG33MI02 - Rev. 2013-11-20
Function:
Reference site Local Remote
set in referen reference
3-13 Reference ce active
Site active [121]
[120]
Reference site: 1 0
Local
3-13 Reference
Site [2]
Reference site: 0 1
Remote
3-13 Reference
Site [1]
Reference site:
Linked to Hand/
Auto
Hand 1 0
Hand ⇒ off
1 0
Auto ⇒ off
0 0
Auto 0 1
Table 3.20 Local Reference Active
Output is high when 3-13 Reference
Site = [1] Remote or [0] Linked to hand/
auto while the LCP is in Auto On
mode. See above.
Output is high when no alarm is
present.
Output is high when the Start
command high (i.e. via digital input,
bus connection or [Hand On] or [Auto
On] ), and a Stop has been last
command.
Output is high when the frequency
converter is running counter clockwise
(the logical product of the status bits
'running' AND 'reverse').
Output is high when the frequency
converter is in [Hand on] mode (as
indicated by the LED light above
[Hand on]).
Output is high when the frequency
converter is in 'Auto' mode (as
indicated by LED on above [Auto
on] ).
Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20] ATEX
3 3
93
