Parameter Descriptions
8-50 Coasting Select
Option: Function:
[3] Logic OR Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
(digital input) and/or via the bus.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
Only selection [0] Digital input is available
when 1-10 Motor Construction is set to [1]
PM non-salient SPM.
[0] Digital Activates Start command via a digital input.
input
[1] Bus Activates Start command via the serial communi-
cation port or fieldbus option.
[2] Logic Activates Start command via the fieldbus/serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-53 Start Select
Option: Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
[0] Digital Activates Start command via a digital input.
input
[1] Bus Activates Start command via the serial communi-
cation port or fieldbus option.
[2] Logic Activates Start command via the fieldbus/serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
®
VLT AutomationDrive FC 301/302 Programming Guide
8-54 Reversing Select
Option:
[0]
[1]
[2]
Function:
[3]
*
8-55 Set-up Select
Option:
[0] Digital
[1] Bus
[2] Logic
[3] Logic OR
8-56 Preset Reference Select
Option:
[0] Digital
[1] Bus
[2] Logic
[3] Logic OR
MG33MI02 - Rev. 2013-11-20
Function:
Digital Select control of the frequency converter
input reverse function via the terminals (digital input)
and/or via the fieldbus.
Bus Activates the Reverse command via the serial
communication port or fieldbus option.
Logic Activates the Reverse command via the
AND fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Logic OR Activates the Reverse command via the
fieldbus/serial communication port OR via one
of the digital inputs.
Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
Activates the set-up selection via a digital input.
input
Activates the set-up selection via the serial
communication port or fieldbus option.
Activates the set-up selection via the fieldbus/
AND serial communication port, AND additionally via
one of the digital inputs.
Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the fieldbus.
Activates Preset Reference selection via a digital
input input.
Activates Preset Reference selection via the serial
communication port or fieldbus option.
Activates Preset Reference selection via the
AND fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Activates the Preset Reference selection via the
fieldbus/serial communication port OR via one of
the digital inputs.
