Parameter Lists
Par. No. # Parameter description
Term. X30/11 Low Ref./Feedb.
6-34 Value
Term. X30/11 High Ref./Feedb.
6-35 Value
Term. X30/11 Filter Time
6-36 Constant
6-4* Analog Input 4
6-40 Terminal X30/12 Low Voltage
6-41 Terminal X30/12 High Voltage
Term. X30/12 Low Ref./Feedb.
6-44 Value
Term. X30/12 High Ref./Feedb.
6-45 Value
Term. X30/12 Filter Time
6-46 Constant
6-5* Analog Output 1
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
6-53 Term 42 Output Bus Ctrl
Terminal 42 Output Timeout
6-54 Preset
6-55 Analog Output Filter
6-6* Analog Output 2
6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale
6-63 Terminal X30/8 Bus Control
Terminal X30/8 Output Timeout
6-64 Preset
6-7* Analog Output 3
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
Terminal X45/1 Output Timeout
6-74 Preset
6-8* Analog Output 4
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
Terminal X45/3 Output Timeout
6-84 Preset
®
VLT AutomationDrive FC 301/302 Programming Guide
Default value 4-set-up
0 ReferenceFeed-
backUnit All set-ups
ExpressionLimit All set-ups
0.001 s All set-ups
0.07 V All set-ups
10 V All set-ups
0 ReferenceFeed-
backUnit All set-ups
ExpressionLimit All set-ups
0.001 s All set-ups
ExpressionLimit All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
[0] Off 1 set-up
ExpressionLimit All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
ExpressionLimit All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
ExpressionLimit All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
MG33MI02 - Rev. 2013-11-20
FC 302 Change Conver-
only during sion index
operation
TRUE -3
TRUE -3
TRUE -3
TRUE -2
TRUE -2
TRUE -3
TRUE -3
TRUE -3
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
Type
Int32
Int32
Uint16 4 4
Int16
Int16
Int32
Int32
Uint16
Uint8
Int16
Int16
N2
Uint16
Uint8
Uint8
Int16
Int16
N2
Uint16
Uint8
Int16
Int16
N2
Uint16
Uint8
Int16
Int16
N2
Uint16
