Danfoss VLT AutomationDrive FC 302 Programming Manual page 133

Parameter Descriptions
3.14.4 13-1* RS Flip Flops
The Reset/Set Flip Flops hold the signal until set/reset.
Par. 13-15
RS-FF Operand S
Par. 13-16
RS-FF Operand R
Illustration 3.50 Reset/Set Flip Flops
2 parameters are used and the output can be used in the
logic rules and as events.
S
R
Flip Flop Output
Illustration 3.51 Flip Flop Outputs
The 2 operators can be selected from a long list. As a
special case, the same digital input can be used as both
Set and Reset, making it possible to use the same digital
input as start/stop. The following settings can be used to
set up the same digital input as start/stop (example given
with DI32 but is not a requirement).
Parameter Setting
Parameter 13-00 SL Controller
On
Mode
Parameter 13-01 Start Event TRUE
Parameter 13-02 Stop Event FALSE
Parameter 13-40 Logic Rule [37] Digital
Boolean 1 [0] Input DI32
Parameter 13-42 Logic Rule
[2] Running
Boolean 2 [0]
Parameter 13-41 Logic Rule [3] AND
Operator 1 [0] NOT
Parameter 13-40 Logic Rule [37] Digital
Boolean 1 [1] Input DI32
Parameter 13-42 Logic Rule
[2] Running
Boolean 2 [1]
Parameter 13-41 Logic Rule
[1] AND
Operator 1 [1]
Parameter 13-15 RS-FF [26]
Operand S [0] Logicrule 0
Parameter 13-16 RS-FF [27]
Operand R [0] Logicrule 1
®
VLT AutomationDrive FC 301/302 Programming Guide
Parameter
Parameter 13-51 SL Controller
Event [0]
Parameter 13-52 SL Controller
Action [0]
Parameter 13-51 SL Controller
Event [1]
Parameter 13-52 SL Controller
Action [1]
Table 3.23 Operators
13-15 RS-FF Operand S
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
Notes
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
Output from 13-41
[34]
[0]
[35]
Output from 13-41
[36]
[1]
[37]
[38]
MG33MI02 - Rev. 2013-11-20
Setting
[94] RS
Flipflop 0
[22] Run
[27]
Logicrule 1
[24] Stop
Function:
False
True
Running
In range
On reference
Torque limit
Current Limit
Out of current range
Below I low
Above I high
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL Time-out 0
SL Time-out 1
SL Time-out 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Notes
Output from
evaluating 13-15
and 13-16
3
