Parameter Descriptions
13-10 Comparator Operand
Array [6]
Option: Function:
[60] On reference The motor is running on reference.
[61] Below The motor is running below the value
reference, low given in parameter 4-54 Warning
Reference Low.
[62] Above ref, high The motor is running above the value
given in parameter 4-55 Warning
Reference High
[65] Torque limit The torque limit, set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode, has been exceeded.
[66] Current Limit The motor current limit, set in
parameter 4-18 Current Limit, has been
exceeded.
[67] Out of current The motor current is outside the range
range set in parameter 4-18 Current Limit.
[68] Below I low The motor current is lower than set in
parameter 4-50 Warning Current Low.
[69] Above I high The motor current is higher than set in
parameter 4-51 Warning Current High.
[70] Out of speed The speed is outside the range set in
range parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
[71] Below speed The output speed is lower than the
low setting in parameter 4-52 Warning Speed
Low.
[72] Above speed The output speed is higher than the
high setting in parameter 4-53 Warning Speed
High.
[75] Out of The feedback is outside the range set in
feedback range parameter 4-56 Warning Feedback Low
and parameter 4-57 Warning Feedback
High.
[76] Below feedback The feedback is below the limit set in
low parameter 4-56 Warning Feedback Low.
[77] Above The feedback is above the limit set in
feedback high parameter 4-57 Warning Feedback High.
[80] Thermal This operand becomes true when the
warning frequency converter detects any thermal
warning, for instance, when the
temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor or thermistor.
[82] Mains out of The mains voltage is outside the
range specified voltage range.
[85] Warning If a warning is triggered, this operand
gets the warning number.
®
VLT AutomationDrive FC 301/302 Programming Guide
13-10 Comparator Operand
Array [6]
Option:
[86] Alarm (trip)
[87] Alarm (trip
lock)
[90] Bus OK
[91] Torque limit &
stop
[92] Brake fault
(IGBT)
[93] Mech. brake
control
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input
DI18
[131] Digital input
DI19
[132] Digital input
DI27
[133] Digital input
DI29
[134] Digital input
DI32
MG33MI02 - Rev. 2013-11-20
Function:
A (trip) alarm is active.
A (Trip lock) alarm is active.
Active communication (no time-out) via
the serial communication port.
If the frequency converter has received a
stop signal and is at the torque limit, the
signal is logic "0".
The brake IGBT is short circuited.
The mechanical brake is active.
The result of comparator 0.
The result of comparator 1.
The result of comparator 2.
The result of comparator 3.
The result of comparator 4.
The result of comparator 5.
The result of Logic rule 0.
The result of Logic rule 1.
The result of Logic rule 2.
The result of Logic rule 3.
The result of Logic rule 4.
The result of Logic rule 5.
The result of SLC timer 0.
The result of SLC timer 1.
The result of SLC timer 2.
The result of SLC timer 3.
The result of SLC timer 4.
The result of SLC timer 5.
The result of SLC timer 6.
The result of SLC timer 7.
Digital input 18. High = True.
Digital input 19. High = True.
Digital input 27. High = True.
Digital input 29. High = True.
Digital input 32. High = True.
